Center and Side Vents
Rotate the thumbwheel downer up to close
or open the grille, and rotate up to open
the grille.
Move the grille button to sides, up or down
to adjust air ow.
Heating & ventilation*
Heating and Ventilation system conducts the fresh
or hot air in the vehicle compartment through the
outlets located in the front of the windshield.
Outlets are used for the windshield, face and feet
of the front passengers (There is also an outlet
on the central console for the rear passengers).
Air distribution adjustment is as follows:
1) Air intake control
2) Cooler
3) Center and side vents
4) Foot wells
5) Windscreen and side windows (de-icing and
de-misting)
6) Air ow adjustment
7) Temperature adjustment
8) Air vents adjustment
