Ikco SAMAND - Page 150

149
5
Front Lamp / High beam
1- Unsrew the cover
2- Press the spring clamps inward, and lift
it up to release.
3- Remove the bulb.
4- Disconnect the connector.
5- Fit the connector, and place the new
bulb without touching the bulb glass.
Align the bulb by the sign on the reector
and place the spring clamps.
6- Ret the cover
Front Lamp / Dipped beam
1- Unsrew the cover
2- Disconnect the connector
3- Release the spring clamps.
4- Fit the connector, and place the new
bulb without touching the bulb glass.
Align the bulb by the sign on the reector
and place the spring clamps.
5- Fit the connector at the back of the bulb.
6-Ret the cover
CHANGING LAMPS
Warning
All the bulbs are vacuumed and maybe broken at the time of changing them and
subsequently cause the wound.
Small bulbs
Connector of the small bulbs is located
beneath the high beam lamp, inside the
lamp body.
1- pull out the lamp and its base.
2- Disconnect the base from the bulb.
3- Press the new bulb in the base then
insert the combination of bulb and base in
its own location.
