Step 2 Lift and pull the latches until they
click.
Step 3 Close the oven door halfway to the
rst opening position. Then lift and
pull to remove the door from its
seat.
Step 4 Put the door on a soft cloth on a sta‐
ble surface.
Step 5 Hold the door trim (B) on the top
edge of the door at the two sides
and push inwards to release the clip
seal.
Step 6 Pull the door trim to the front to re‐
move it.
Step 7 Hold the door glass panels by their
top edge and carefully pull them out
one by one. Start from the top pan‐
el. Make sure the glass slides out of
the supports completely.
Step 8 Clean the glass panels with water and soap. Dry the glass panels carefully. Do
not clean the glass panels in the dishwasher.
Step 9 After cleaning, install the glass panels, the door trim and the oven door, close
the latches on the both hinges.
If the door is installed correctly, you will hear a click when closing the latches.
