IKEA LAGAN - Page 28

Removing and Replacing the Oven
Door
Figure 17: Door hinge location
Oven door
hinge
locations
Figure 18: Door hinge Locks
Figure 19: Holding door for removal
Figure 20: Replacement and location of hinge
arm and roller pin
To remove the oven door:
1. Open oven door completely, horizontal with
oor.
2. Pull the door hinge locks on both left and right
door hinges down from the oven frame com-
pletely towards the oven door (See Figure 188).
A tool such as a small at-blade screwdriver
may be required.
3. Firmly grasp both sides of oven door along the
door sides. Do not use the oven door handle
(Figure 199)
4. Close the door to approximately 10 degrees
from the door frame (Figure 199).
5. Lift the oven door hinge arms over the roller
pins located on each side of the oven frame
(Figure 2020)
To Replace Oven Door:
1. Firmly grasp both sides of oven door along the
door sides. Do not use the oven door handle
(Figure 199).
2. Holding the oven door at the same angle as the
removal position, seat the hook of the hinge
arm over the roller pins located on each side
of the oven door frame (See Figure 2020). The
hook of the hinge arms must be fully seated
onto the roller pins.
3. Fully open the oven door, horizontal with oor
(Figure Figure 177).
4. Push the door hinge locks up towards and into
the oven frame on both left and right oven door
hinges to the locked position (Figure 188).
5. Close the oven door.
roller
pin
hing
e
arm
L
O
C
K
about
10°
hinge
oven
door
IMPORTANT
Special door care instructions - Most oven doors contain
glass that can break. Do not hit the glass with pots,
pans, or any other object. Scratching, hitting, jarring, or
stressing the glass may weaken its structure, causing an
increased risk of breakage at a later time. Do not close
the oven door until all of the oven racks are fully in place
.
CAUTION
The door is heavy. For safe, temporary storage, lay
the door at with the inside of the door facing down.
28
EN
CARE AND CLEANING
