Replacing the Oven Light
Figure 21: Oven light protected by glass
shield
Replacing the oven interior light bulb:
The interior oven light is located at the rear of the
oven cavity and covered with a glass shield. The
glass shield must be in place whenever the oven is
in use (Figure Figure 211).
1. Turn electrical power off at the main source or
unplug the appliance.
2. Remove the interior oven light shield
3. Pull the shield straight out. Do not twist or turn.
4. Replace the bulb with a new appliance bulb.
5. Replace the glass oven light shield.
6. Turn the power back on again at the main source
(or plug the appliance back in).
7. Be sure to reset the time of day on the clock.
Removing the Storage Drawer
Use the storage drawer for storing cooking utensils.
The drawer can be removed to facilitate cleaning
under the range.
Use care when handling the drawer.
CAUTION
Be sure the oven is unplugged and all parts are
cool before replacing the oven light.
Figure 22: Open storage drawer
Figure 23: Closed storage drawer
Cleaning under bake element
The bake element is located in the lower oven cavity.
For some models, if the lower bake element is visible
it may be tilted up for easier access to the oven bot-
tom for cleaning. Remove the oven racks before rais-
ing the element. Be careful not to raise the element
more than 4 or 5 inches from the resting position.
oven
light
29
EN
CARE AND CLEANING
