4).
To refit the door
1. Insert the hinges in their seats.
2. Open the door fully.
3. Lower the two catches.
4. Close the door
Cleaning the glass
1. After removing the door and resting it on a soft surface with the handle downwards,
simultaneously press the two retaining clips and remove the upper edge of the door by pulling it
towards you.
2. Lift and firmly hold the inner glass with both hands, remove it and place it on a soft surface before
cleaning it.
3. To reposition the internal glass properly, be sure that the “R” can be seen in the left corner.
First insert the long side of the glass indicated by “R” into the support seats, then lower it into
position.
4. Refit the upper edge: A click will indicate correct positioning. Make sure the seal is secure before
refitting the door.
