IKEA RAFFINERAD User Manual

ENGLISH 8
Inserting wire shelves and other accessories
in the oven
1. Insert the wire shelf horizontally, with the
raised part “A” upwards (Fig. 1).
A
Fig. 1
2. Other accessories, such as the drip tray
and baking tray, are inserted in the same
way as the wire shelf (Fig. 2).
Fig. 2
Remove the blue lm as shown in the image
How you align the tray with the telescopic
runners.
Place the drip tray on the telescopic runners
xing it between the rear and front fastener.
Fig. 2
Fig. 3

IKEA RAFFINERAD Specifications

General

Energy class	A
Color	Stainless steel
Voltage	220-240V
Installation type	Built-in
Volume	72 liters
Functions	Grill, Defrosting function
Oven features	Child lock
Cleaning	Catalytic
Frequency	50 Hz
