OPERATION
4
4.1 Operating Procedures
4.1 Operating Procedures
This chapter explains how to operate the HDK-55 camera.
■
Initial Operation Check
――――――――――――――
When you use the camera for the first time after purchase, ensure that it works properly.
◆
Switch Position Check
･･･････････
(page 58)
◆
Turning ON Power
･･････････････
(page 60)
◆
Output Signal Check
････････････
(page 63)
- Color-Bar Signal Check
- Test Pulse Check (CAL Signal)
- Check by Use of External Chart
■
Preparation Before Shooting
―――――――――――――――――
◆
Viewfinder Adjustment
･･････････････
(page 62)
- Diopter Adjustment and Screen Adjustment
- Display Mode Check
◆
Output Signal Check
････････････････
(page 63)
- Color-Bar Signal Check
- Test Pulse Check (CAL Signal)
- Check by Use of External Chart
◆
Auto Setup
････････････････････････
(page 65)
<
Pattern 1
>
1 Auto Black Balance (ABB)
2 Auto White Balance (AWB)
<
Pattern 2
>
1 Black Shading
2 Auto White Balance (AWB)
(Execute one of the above patterns.)
■
Shooting Settings and Adjustment
――――――――――――――――――――
Make IRIS and pedestal adjustments and various function settings according to the environment in which the camera
is used.
◆
Camera menu settings
Refer to "5. CAMERA SETTINGS and ADJUSTMENT" (page 71).
◆
BS menu settings
Refer to the operation manual accompanying BSF-55 to be used.
