System Parameter Editing Commands and Companion Queries

These commands are used to modify the system parameters for the tester. These commands require a parameter value to be

included with the command.

Query Commands

These query commands will retrieve data from the tester. These commands include functions for retrieving test data, test results

and remote hardware.

TD? - Read the active data being displayed on the LCD display while the test is in process. It will also read the last data taken

when the test sequence has completed. Each parameter is separated by commas and includes memory location, test type, test

status, and metering. The syntax for this command response is {memory - step, test type, status, meter 1, meter 2, meter 3}.

{Memory, GND, Status, Current(A), Resistance(mΩ), Time(s)}

RD <step number>? - Read the results for an individual memory location. Each parameter is separated by commas and

includes memory location, test type, test status, and metering. The syntax for this command response is {memory - step, test

type, status, meter 1, meter 2, meter 3}.

{Memory, GND, Status, Current(A), Resistance(mΩ), Time(s)}

RR? - Read the remote Reset input signal. When the remote reset has to be activated by closing the contacts the query will

return a value of 0 to indicate the tester is being Reset.

Command Name Value

SPR {1|0}

SPR?

PLC Remote ON/OFF 1=On, 0=O

SEC < 0 > Edit Security OFF 0=O

SEC < value, mmm>

SEC?

Edit Security ON,

Passcode

1=RUN, 2=MEM, mmm = 000 – 999 (Passcode)

Command Name Value

TD? List Testing Data Data from test in Process

RD <memory location>? Result Data Query by

memory locaiton

1-5

RR? Read Reset Query 1=Open, 0=Closed

RI? Read Interlock Query 1=Open, 0=Closed

RDM Read Current Max Maximum current measured during the test including Ramp

Up and Dwell Time

LS? List Step Parameters Memory, GND, Current(A), HI-Limit(mΩ), LO-Limit(mΩ), Dwell(s),

Frequency(Hz), Oset(mΩ), Connect

LS <memory location>? List Step Parameters by

memory location

Memory Location = 1-5

IKONIX SCI 290 Series User Manual
