hipot.com 53
RI? - Read the remote Interlock input signal. When the remote Interlock has to be activated by opening the contacts the query
will return a value of 1 to indicate the tester is in the Interlock state and will not be able to generate output voltage or current.
RDM? - Read the remote Interlock input signal. When the remote Interlock has to be activated by opening the contacts the
query will return a value of 1 to indicate the tester is in the Interlock state and will not be able to generate output voltage or
current.
LS? - Lists all the Parameters for the individual step that is currently selected.
The response will be formatted as follows;
{Memory, ACW, Status, Voltage(kV), Current(mA), Time(s)}
{Memory, DCW, Status, Voltage(kV), Current(mA), Time(s)}
{Memory, DCW, Status, Voltage(kV), Current(mA), Time(s)}
LS <memory location>? - Lists all the Parameters for the individual step indicated by step number = 1-5.
The response will be formatted as follows;
SFW? - Return the current rmware version of the tester.
IEEE 488.2 Common Commands
These commands are required by the IEEE-488.2 standard with the exception of *PSC, *PSC?. Most of these commands are not
available over the RS-232 bus except for the *IDN? command which can be used to retrieve the tester identication information,
and the four status reporting commands *ESR?, *ESE, *ESE? and *STB?.
Command Name Description
*IDN? Identication Query SLA, Model Number, Serial Number, Firmware
Revision
*RST Reset Command Reset Tester
*TST? Self-Test Query 00H=OK
01H=TEST EEPROM ERROR
*CLS Clear Status Command Clear Standard Event Status Register
Clear Service Request Register
*OPC Operation Complete Command When TEST command ok setting ESR BIT0 =1
*OPC? Operation Complete Query 1 = TEST completed ok
0 = TEST in process
*WAI Wait-to-Continue
Command
*PSC {1|0} Power-on Status Clear Command 1 = Power-on clear enable registers
0 = Power-on load previous enable registers
*PSC? Power-on Status Clear Query
