1. Antenna: Transmits signal to the receiver located in the vehicle. Flip up
when transmitter in use. Fold for storage.
2. Multifunction Red Indicator LED:
a. Power indicator.
b. Low battery voltage warning, batteries should be replaced/recharged before
continued use when ashing.
c. Model indicator.
3. Dual-Rate Adjustment/Memory Reset: Adjusts total travel of servo in both
directions.
4. Ch. 4/Fail-Safe: Toggle Ch. 4 ON/OFF. Use to set the Fail-Safe in case of
signal loss.
5. REV/Pair:
a. Use to reverse servo/channel operation.
b. Use to put the transmitter into pairing mode.
6. Digital Trim: All switches are digital so there is no need to readjust trim
position for different models after initial setup.
a. Steering: Controls the “hands-off” left/right direction of the vehicle.
b. Throttle: Adjusts the motor speed to STOP when trigger is in ‘hands-off’ (neutral)
position.
7. Steering Wheel: Controls left/right motion (note that the wheel can be
re-positioned and/or congured for left-hand use.
8. Battery compartment: Houses [4] AA batteries or a NiMH rechargeable
battery pack for powering the transmitter.
9. Adjustable Grip: For holding the transmitter. Use included grip sizes to
adjust for your hand size.
10. ON/OFF Switch: Turns the power ON/OFF for the transmitter.
11. Throttle Trigger: Controls forward/reverse/brake motion (designed to be
operated with index nger).
12. Mode Switch:
a. Standard Mode: All functions are fully operational.
b. Feature Lock: Disables all buttons except Steering Trim.
c. Beginner Mode: Reduces throttle output to 50%.
13. Model Select: Use to select a model when powering ON the transmitter.
14. Channel 3 adjustment knob.
