ilco 045 HD - Exploded View Parts List

Ref. Part no. Description
1 045HD-1 Carriage
1X 045HD-1X Carriage assembly
2 025-2 Carriage stud
3X 045HD-3X Vise jaw assembly (Super Jaw 3)
4 025-4 Vise jaw spring
6X 025-6X Thrust bearing set
8 025-8 Wing nut
9X 040-9X Carriage handle
20 040HD-20 Cutter shaft bearings
21 025-21 Carriage shaft bushing
23 045HD-23 Carriage shaft
32 024B-32 Button head. screw, 10-24 x
3
⁄8"
36 025-36 Cutter nut, N-4
37 025-37 Cutter spacer; left
38 P-X23MC P-X23MC cutter
40 040HD-40 Cutter shaft
41 025-41 Cutter shaft pulley
43 814-00-51 Nylon brush
45 024-45 Brush bolt washer,
5
⁄1
6
46A 025-46A Hex head screw,
5
⁄16-18 x
3
⁄4
47 025-47 Motor pulley 2" - 3L
48 025-48 V-Belt, 3L-180
49 045-49 Cutter guide (stylus)
50 040-50 Carriage stop
52 040-52 Socket hd. screw 8-32 x 1-1/2"
53 045-53A Cutter guide binding washer
54 045-54 Cutter guide binding screw
55A 045-55A Adjusting screw
56 040-56 Key gauge
57 024B-57 Key gauge bracket
58
024B-58
Key gauge dowel pin
59
025-59
Key gauge housing
60 025-60 Cap screw, 8-32 x
1
⁄2"
61
025-61
Cir
cuit Br
eaker
, ETA 1658
62A
025-62A
On/Off switch
65 045HD-65 Machined base
68
040-68
Electrical cover
70 040-70 Rubber mount
74 040-74 Truss head screw, 8-32
75 040-75
Motor
,
1
⁄4hp,115V
Ref. Part no. Description
79 024B-79 Key gauge spring
84 024B-84 Clip
86X 045HD-86X Safety hood assembly
87 045HD-87 Safety shield
89 045-89 #10 Lockwasher
90 025-90 Nut, #10-32
91 024B-91 Power cord
92 024B-92 3 wire motor cable
100 040HD-100 Cutter spacer; right
101 025-101 Motor pulley set screw
106 040-106 Chip tray
109 025-109 Bearing washer
110 025-110 Wave washer
129 040-129 Locking nut (8-32)
146 040-146 Power cord strain relief
150 040-150 Switch screw (6-32 x 1/4")
151 040-151 Set screw (8-32 x 3/8")
160 025-160 Caution label
163 045-163 Hood Screw
171 025-171 Cutter pulley set screw,
3
⁄8" -18
181 024B-181 Key Gauge Spacer - Left
182 024B-182 Key Gauge Spacer - Right
183 040-183 1/4-20 Lockwasher
184 040-184 1/4-20 Hex Nut
186 045-186 6-32 x 3/8" set screw
187 045-187 dowel
188 045-188 dowel spring
189 045-189 Adjustment dial
190 045-190 Cutter guide label
194 045-194 #10 flat washer
195 045-195 10-32 x 1/2" Button hd. screw
198
045-198
7/16-14 x 3/4" set scr
ew
199 045-199 1/2-20 x 1/2" set screw
IM 045HD-IM Instruction manual
NS 025-240 220V
1
⁄4 HP motor
EXPLODED VIEW PARTS LIST
8
Refer to pages 6-7 for illustration
