iLight SCI1210 User Manual

SCS1210S - Single pole
SCS1210N - Neutral disconnect
SCS1220S - Single pole
SCS1220N - Neutral disconnect
Common specifications as detailed on
page 12 plus the following features:
Key Features
l Twelve channels of switching for resistive, inductive
or capacitive lighting loads.
l Quiet operation.
SCS1210
l 12 x 10 Amp fully rated switching Source Controller.
SCS1220
l 12 x 20 Amp Source Controller.
Mechanical Data
SCS1210, SCS1220
l Weight: 7.5kg.
UK version
l Mains Cable Access: 12 x 25 mm, 1 x PG29
knockouts.
l Control Cable Access: 1 x 25 mm knockout.
Euro version
l Mains Cable Access: 12 x PG16 and 1 x PG29
knockouts.
l Control Cable Access: 1 x PG16 knockout.
Switched Relay Controllers
17 of 23
Electrical Data
Load Types
l This unit is designed to work with most lighting load
types. Please consult with the iLight™ help desk for
guidance on true load calculations. Care should be
taken when specifying discharge lighting sources.
Switched Outputs
l This device uses 12 x 230 volt 20A (resistive and
inductive) relays.
Terminal Sizes
l Incoming supply, maximum cable size: 10mm
2
.
SCS1210
l Maximum Load: 40 Amp three phase @ 40ºC.
l Maximum Channel Current: 10 Amps.
l Supply: 415/230 volts -/+ 10% 50/60 Hz.
(optionally, 220/127 volt 60 Hz).
l Protection: 12 x 10 Amp MCB’s type C, 6KA rated.
SCS1220
l Maximum Load: 63 Amp three phase @ 40ºC.
l Maximum Channel Current: 20 Amps.
l Supply: 415/230 volts -/+ 10% 50/60 Hz.
(optionally, 220/127 volt 60 Hz).
l Protection: 12 x 20 Amp MCB’s type C, 6KA rated.
