iLive ITTB401DW - Assembly

8
Assembly
Belt Plate
Belt
Step 1
Place the Belt plate onto the main
unit as seen below.
Step 2
Pull the Belt of the Belt Plate around the
Roller as shown below.
Step 3
Place the Plate Cover over the Belt Plate as shown
below. You may now load a record onto the turntable.
Roller
Plate Cover
