MATRIX MANUAL 2014
Illusion-Australian Made Gas Log Fires
Main Gas Connection
The connection is made using gas pipes with Rp1/2 ISO 7 threading. Torque: 25Nm
If, alternatively, anges are used, rst screw the pipes on to the anges and then the
anges to the valve. Recommended torque for the ange xing screws: 3Nm.
A suitable Certied exible stainless steel pipe may be used from the valve to the incoming gas line. It is recommended
that an Certied shutoff valve be tted between the incoming gas line and the appliance to enable the gas
supply to the appliance to be shut off independantly from the mains gas supply.
Caution: After making the connections, check gas tightness.
IMPORTANT NOTE TO INSTALLER
Caution: Check the appliance before leaving.
Check that logs are correctly located. Incorrect location of logs
will affect combustion and may cause sooting.
Check the gas pressure.
Light the appliance and check for ame abnormalities on both high and low ame
settings. Flames should not lift off the burner ports. Allow the unit about 5 minutes to
warm up then if the ames are lifting from the burner ports it may be necessary to
adjust the gas pressure on the gas valve.
THE FOLLOWING INDICATES SITUATIONS OF ABNORMAL OPERATION OF THE APPLIANCE.
WHEN THE APPLIANCE IS OPERATING :
1. The ames appear excessively large and / or sooting occurs on the logs.
2. You can smell gas.
3. The ame pattern is inconsistent and appears to be lifting off the burner.
4. You can smell the products of the ue within the room in which the appliance is installed. (May be an
indication of a blocked ue)
If any of the above situations occur, turn the appliance off, and contact your supplier or installer
immediately. If you can smell gas, turn the gas off at the mains and call the appropriate authority.
Always call from outside the building from a neighbors, or with a mobile phone.
ABNORMAL OPERATION
Manufactured by Illusion Australia Pty. Ltd. 145 South Gippsland Hwy.
Dandenong 3175 Victoria Australia
Phone: 613 9793 7520
ILLUSION GAS LOG FIRES - MODELS GFX-L/NG, GFX-M/NG, GFX-S/NG
NOTE: TABLE BELOW RELATES TO ALL VARIATIONS OF EACH SIZE APPLIANCE
SAI GLOBAL APPROVAL CERTIFICATE NOS: GSCS20033 GSCS20043 GSCS20034
Electrical components conform to AS 3100 240V 50hz 60 watts
Model MATRIX-GFX-L/NG MATRIX-GFX-M/NG MATRIX-GFX-S/NG
Injector Size 3.00 2.7 2.5
Nominal Gas Consumption Mj/h 40.0 34.0 28.0
Gas Type NAT NAT NAT
Turndown Pressure kPa .34 .32 .50
Manifold Pressure kPa .82 .78 .90
Kilowatt Rating (Vertical Flue) On High 8.41 7.14 5.64
Kilowatt Rating (Horizontal Flue) On High 7.87 6.86 5.71
