MILLENIUM FREESTANDING MANUAL 2014
Quality & Value In Gas Log Fires
Your new ILLUSION Gas Log Heater represents the pinnacle of many years’ research and development.
The combination of innovative features designed for Australian conditions and a genuine Log Fire appearance
ensures this appliance is the Ultimate in Gas Log Fires.
The ILLUSION Gas Log Fire provides you with continuous warmth, and the traditional charm of a wood red heater,
without the hard work generally associated with a wood fuelled appliance.
Safe and economical, you can rest easy knowing the ILLUSION Gas Log Fire has been fully tested and approved to
AUSTRALIAN STANDARD AG 103.
NOTE: ILLUSION GAS LOG HEATERS - MODELS UGL33NG & UGL40NG ARE DESIGNED AND TESTED
TO BE INSTALLED WITH THE SUPPLIED FLUE KIT ONLY. THESE UNITS MUST ONLY BE INSTALLED
BY AN AUTHORISED INSTALLER.
TABLE OF CONTENTS
PAGE DESCRIPTION
1. UGL33 DIMENSIONS
2. UGL40 DIMENSIONS
3. MAIN GAS CONNECTION & LABELLING
4. LIGHTING INSTRUCTIONS
5. INSTALLATION FOREWORD & SAFETY INFORMATION
6. INSTALLATION INSTRUCTIONS
7. INSTALLATION CLEARANCES
8. INSTALLATION EXAMPLES
9. FITTING THE LOGS & COAL UGL33
10. FITTING THE LOGS & COALS UGL33 (CONTINUED)
11. FITTING THE LOGS & COALS UGL40
12. FITTING THE LOGS & COALS UGL40 (CONTINUED
13. PRESSURE TESTING
14. INSTALLATION FLUE SPILLAGE TEST
15. MAINTENANCE
16. DOOR REMOVAL INSTRUCTIONS
17. PARTS ASSEMBLY EXPLODED VIEW
18. THERMOSTATICALLY CONTROLLED FAN
19. REMOTE CONTROL HANDSET OPERATION
20. ABNORMAL OPERATION
21. TROUBLESHOOTING
22. ILLUSION CONTACT DETAILS
