MILLENIUM FREESTANDING MANUAL 2014
Quality & Value In Gas Log Fires
3
ILLUSION GAS LOG HEATERS - MODELS UGL33NG, UGL40NG, UGL33LP AND UGL40LP
DO NOT
DO NOT
DO NOT
DO NOT
OPERATE THIS APPLIANCE BEFORE READING THE
INSTRUCTION BOOKLET
PLACE ARTICLES ON OR AGAINST THIS
APPLIANCE
STORE CHEMICALS OR FLAMMABLE MATERIALS
OR SPRAY AEROSOLS NEAR THIS APPLIANCE
OPERATE WITH PANELS, COVERS OR GUARDS
REMOVED FROM THIS APPLIANCE
THE GUARD IS FITTED TO THIS
APPLIANCE TO REDUCE THE RISK
OF FIRE OR INJURY FROM BURNS
AND NO PART OF IT SHOULD BE
PERMANENTLY REMOVED.
FOR THE PROTECTION OF YOUNG
CHILDREN OR THE INFIRM,
A SECONDARY GUARD IS REQUIRED.
PLEASE NOTE A S P E R A G A 1 0 3 A P R I M A R Y S A F E T Y G U A R D I S S U P P L I E D
AND MUST BE FITTED WHEN THE HEATER IS OPERATING.
Electrical components conform to AS 3100 240V 50hz 60 watts
AGA APPROVAL NUMBER- 6286-01
Model UGL33NG UGL40NG UGL33LP UGL40LP
Injector Size (mm) 3.0 3.8 1.8 1.8
Manifold Pressure (kPa) .83 .73 1.25 2.25
Gas Consumption (Mj/h 33 40 28 37
Gas Type NAT NAT LP LP
Average Efciency (%) 76.1 77.9 72 72
Max Output (kW/h) 7.19 8.6 5.74 7.58
Main Gas Connection
The connection is made using gas pipes with Rp1/2 ISO 7 threading. Torque: 25Nm
If, alternatively, anges are used, rst screw the pipes on to the anges and then the
anges to the valve. Recommended torque for the ange xing screws: 3Nm.
Connection to the pilot burner
Pipes with Ø 4mm, Ø 6mm or Ø 1/4 can be used. Use a nut and olive of appropriate dimensions.
Tighten the nut to 7 Nm torque.
Electrical Connections
Use the special connectors for connection to the thermopile and to the thermostat.
Make the connections in accordance with the plan below and in accordance with the rules for the appliance. The elec-
trical safety cut off devices (for example, the ame failure device, limit thermostat and the like) must cut off the power
supply to the thermoelectric circuit of the gas valve.
Caution: After making the connections, check gas tightness.
LABELLING
Manufactured by
Illusion Australia Pty. Ltd.
145 Sth Gippsland Hwy.
Dandenong Sth.
3175
Victoria Australia
