MACHINE PARTS
B
O
P
D
E
F
A
C
Q
I
H
G
A TEMPERATURE INDICATOR LIGHT
(indicates the machine status)
B MAIN ON/OFF SWITCH
C COFFEE BREW BUTTON
(starts and stops coffee fl ow)
D COFFEE BREW HEAD
E TRAY FULL FLOAT
F CUP GRILL
G STEAM BUTTON
H DRIP TRAY (placed beneath cup grill)
N
M
L
I CAPSULE HOLDER
(for “Metodo Iperespresso” capsules)
L CUP HOLDER
M INTERNAL BEEPER
(emits an audible signal to the user)
N POWER CORD
O STEAM WAND
P WATER TANK
Q DATA PLATE (on bottom)
