iLO IWF2706 - Specifications

1-1 L4805SP
SPECIFICATIONS
Test input
Video input: 1V p-p
Audio input: 500mV rms
Tuner: Ant input (80dBuV) Video 87.5%
< DEFLECTION >
< VIDEO & CHROMA >
< TUNER >
< ATSC >
Description Condition Unit Limit
1. Over Scan
Horizontal
Vertical
%
%
90±5
90±5
2. Linearity
Horizontal
Vertical
%
%
±15
±10
3. High Voltage --- kV 25 to 33
Description Condition Unit Limit
1. Contrast control range --- dB >6
2. Brightness APL 100% ft-L >20
3. Color Temperature --- °K 9200
Description Condition Unit Limit
1. Video S/N --- dB >43
2. Audio S/N (W/LPF) --- dB >45
Description Condition Unit Limit
1. RECEIVED FREQ. RANGE
(-28dBm)
+kHz>100
–kHz>100
2. ATSC DYNAMIC RANGE (min./max.)
VHF LOW BAND. CH.4
VHF HI BAND. CH.10
UHF BAND. CH.41
---
dBm
dBm
dBm
-76/0
-76/0
-74/4
3. ATSC SUSCEPTIBILITY TO
RANDOM NOISE
VHF LOW BAND. CH.4
VHF HI BAND. CH.10
UHF BAND. CH.41
---
dB
dB
dB
<26
<26
<26
4.
NTSC CO-CHANNEL INTERFERENCE
VHF LOW BAND. CH.4
VHF HI BAND. CH.10
UHF BAND. CH.41
---
dB
dB
dB
>-6
>-6
>-6
