20060224 14-3 L4803EL
D502# ZENER DIODE MTZJT-7722B QDTB00MTZJ22
D503# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D553 ZENER DIODE MTZJT-7715B QDTB00MTZJ15
D557 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D558 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D572 DIODE FR104-B NDLZ000FR104
D580# DIODE ERD07-15 QDLZ0ERD0715
D582# FAST RECOVERY DIODE ERD38-06 QDQZ0ERD3806
D583 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D585 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D586 DIODE FR104-B NDLZ000FR104
D591# ZENER DIODE MTZJT-7736B QDTB00MTZJ36
D594# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D595# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D597 ZENER DIODE MTZJT-774.3B QDTB0MTZJ4R3
D605# DIODE 1N5406 NDLZ001N5406
D606# DIODE 1N5406 NDLZ001N5406
D607# DIODE 1N5406 NDLZ001N5406
D608# DIODE 1N5406 NDLZ001N5406
D611# ZENER DIODE MTZJT-7724C QDTC00MTZJ24
D612# ZENER DIODE MTZJT-7739B QDTB00MTZJ39
D613 ZENER DIODE MTZJT-774.3B QDTB0MTZJ4R3
D614 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D615# SWITCHING DIODE 1N4148 T-77 QDTZ001N4148
D623 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D624 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D633 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D650 RECTIFIER DIODE FR202-B/P NDQZ000FR202
D651 DIODE ERD29-06J QD4Z0ERD2906
D652 DIODE FR154 NDLZ000FR154
D653 DIODE FR154 NDLZ000FR154
D654 DIODE FR104-B NDLZ000FR104
D655 DIODE ZENER 1ZB180(Q) QDLZ01ZB180Q
D656# ZENER DIODE MTZJT-777.5B QDTB0MTZJ7R5
D657 DIODE FR154 NDLZ000FR154
D659 SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
D661# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D662 ZENER DIODE MTZJT-7712B QDTB00MTZJ12
D666 ZENER DIODE MTZJT-7733B QDTB00MTZJ33
D670 SCHOTTKY BARRIER DIODE SB140 NDQZ000SB140
D671 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D672 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D676 ZENER DIODE MTZJT-7715B QDTB00MTZJ15
D681 ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D696 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D841# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D842# ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D904 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D905 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D906 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D907 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D908 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D909 ZENER DIODE MTZJT-776.2A QDTA0MTZJ6R2
D910 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
ICS
IC31 IC VIF/SIF M61116FP TF0G QSZBA0SHT034
IC301 MICRO-COMPUTER/VCD R2J10051-M02FP-
RF0S
QSZAA0RHT112
IC381 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
IC421 IC BR24L64F-WE2 QSZBA0TRM071
IC451 IC MTS DECORDER AN5832SA-E1V QSZBA0TMS003
IC551# IC VERTICAL OUTPUT LA78041-E QSZBA0SSY006
IC601# PHOTOCOUPLER LTV-817C-F NPEC0LTV817F
Ref. No. Description Part No.
IC701 IC SWITCHING TC4052BF(ELNF) QSZBA0TTS162
IC801 IC AN17812A QSZBA0SMS017
IC903 VOLTAGE REGULATOR PQ070XF01SZH QSZBA0SSH054
IC904 VOLTAGE REGULATOR PQ070XF01SZH QSZBA0SSH054
IC905 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
IC911 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
COILS
L12 INDUCTOR 33µH-K-5FT LLARKBSTU330
L34 INDUCTOR 18µH-J-26T LLAXJATTU180
L50 INDUCTOR 150µH-J-26T LLAXJATTU151
L51 PCB JUMPER D0.6-P5.0 JW5.0T
L302 INDUCTOR 33µH-K-5FT LLARKBSTU330
L303 INDUCTOR 33µH-K-5FT LLARKBSTU330
L304 PCB JUMPER D0.6-P5.0 JW5.0T
L551 LINEARITY COIL ELH5L6136N LLBD00PMS008
L562 CHOKE COIL ELC18B471LM LLC471KMS001
L564 CHOKE COIL ELC18B821LK LLC821KMS001
L588 CHOKE COIL 47µH LLBD00PKV022
L601# LINE FILTER JLB2460 LLBG00ZXB012
L901 CHOKE COIL 22µH-K LLBD00PKV021
TRANSISTORS
Q61 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q322 TRANSISTOR 2SA1175(F) QQSF02SA1175
Q351 RES. BUILT-IN TRANSISTOR BA1F4M-T QQSZ00BA1F4M
Q352 RES. BUILT-IN TRANSISTOR BA1F4M-T QQSZ00BA1F4M
Q381 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q382 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q383 TRANSISTOR 2SC2120-O(TE2 F T) QQS02SC2120F
Q552# TRANSISTOR 2SD1666R QQER02SD1666
Q571# TRANSISTOR 2SC5978 QQZZ02SC5978
Q572 TRANSISTOR KTC3227-Y-AT/P NQSYKTC3227P
Q601# FET 2SK3869(Q) QFWZ2SK3869Q
Q602# TRANSISTOR 2SC2120-O(TE2 F T) QQS02SC2120F
Q631 TRANSISTOR 2SA1175(F) QQSF02SA1175
Q647 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q652# TRANSISTOR 2SC2785(F) QQSF02SC2785
Q672# TRANSISTOR 2SA1175(F) QQSF02SA1175
Q673 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q674 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q681# TRANSISTOR 2SC2785(F) QQSF02SC2785
Q682# TRANSISTOR 2SC2120-O(TE2 F T) QQS02SC2120F
Q696 NPN TRANSISTOR KRC105M-AT/P NQSZKRC105MP
Q811 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q901 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
Q902 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q903 TRANSISTOR 2SC2120-O(TE2 F T) QQS02SC2120F
Q904 TRANSISTOR 2SC2120-O(TE2 F T) QQS02SC2120F
Q910 TRANSISTOR 2SC2120-O(TE2 F T) QQS02SC2120F
Q911 RES. BUILT-IN TRANSISTOR BA1F4M-T QQSZ00BA1F4M
RESISTORS
R12 PCB JUMPER D0.6-P5.0 JW5.0T
R13 CHIP RES.(1608) 1/10W 0 Ω RRXAJR5Z0000
R24 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R25 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R31 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R32 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R33 CHIP RES. 1/10W J 270 Ω RRXAJR5Z0271
R35 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R37 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R44 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R50 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R51 CHIP RES. 1/10W J 330k Ω RRXAJR5Z0334
Ref. No. Description Part No.
