20060224 14-6 L4803EL
CRT CBA
R912 CHIP RES.(1608) 1/10W F 3.3k Ω RRXAFR5H0332
R913 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R914 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122
R915 METAL RESISTOR 1W J 3.9 Ω RN013R9ZU001
R916 CHIP RES. 1/10W J 1.2k Ω RRXAJR5Z0122
R917 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R918 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R919 CHIP RES. 1/10W J 5.6k Ω RRXAJR5Z0562
R920 CHIP RES.(1608) 1/10W 0 Ω RRXAJR5Z0000
R921 CHIP RES.(1608) 1/10W 0 Ω RRXAJR5Z0000
R922 CARBON RES. 1/4W J 390 Ω RCX4JATZ0391
R923 CHIP RES. 1/10W J 680 Ω RRXAJR5Z0681
R924 CHIP RES.(1608) 1/10W 0 Ω RRXAJR5Z0000
R925 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R926 CHIP RES. 1/10W J 820 Ω RRXAJR5Z0821
R927 CHIP RES. 1/10W F 150 Ω RRXAFR5H1500
R928 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R929 CHIP RES.(1608) 1/10W F 220 Ω RRXAFR5H0221
R930 CHIP RES.(1608) 1/10W F 22k Ω RRXAFR5H0223
R931 PCB JUMPER D0.6-P15.0 JW15.0T
R932 CARBON RES. 1/4W J 1.2 Ω RCX4JATZ01R2
R933 CARBON RES. 1/2W J 2.2 Ω RCX2JZQZ02R2
R934 CHIP RES.(1608) 1/10W F 4.7k Ω RRXAFR5H0472
SWITCHES
SW401 TACT SWITCH SKQSAB SST0101AL038
SW402 TACT SWITCH SKQSAB SST0101AL038
SW403 TACT SWITCH SKQSAB SST0101AL038
SW404 TACT SWITCH SKQSAB SST0101AL038
SW405 TACT SWITCH SKQSAB SST0101AL038
SW406 TACT SWITCH SKQSAB SST0101AL038
MISCELLANEOUS
AC601# AC CORD LP-11W&PT218P-K90A&S WAC0172LW020
B2 HEAT SINK(PKZ) ASSEMBLY L4800UZ 1EM422098
B3 HEAT SINK(PKS)ASSEMBLY L3820UA 1EM421044
B4 HEAT SINK(PKX)ASSEMBLY L4800UZ 1EM422090
B5 HEAT SINK(PLA) L4800UZ 1EM422099
B6 HEAT SINK(PIK) L2800UA 0EM408530
B7 SHIELD PLATE L4800UZ 1EM422101
BC14 PCB JUMPER D0.6-P5.0 JW5.0T
BC15 BEAD INDUCTORS FBR07HA121TB-00 LLBF00ZTU021
BC571 BEAD INDUCTORS FBA04HA600VB-00 LLBF00STU026
BC572 BEAD INDUCTORS FBA04HA600VB-00 LLBF00STU026
BC603 BEAD INDUCTORS FBR07HA121TB-00 LLBF00ZTU021
BC652 BEAD INDUCTORS FBR07HA121TB-00 LLBF00ZTU021
BC653 BEAD INDUCTORS FBR07HA121TB-00 LLBF00ZTU021
BC655 BEAD INDUCTORS FBR07HA121TB-00 LLBF00ZTU021
BC657 BEAD INDUCTORS FBR07HA121TB-00 LLBF00ZTU021
BC691 BEAD INDUCTORS FBR07HA121TB-00 LLBF00ZTU021
CF32 CERAMIC FILTER SFSRA4M50CF00-B0 FBB455PMR004
CLN301 WIRE ASSEMBLY WX1L1200-102 WX1L1200-102
CLN501 WIRE ASSEMBLY WX1L1520-101 WX1L1520-101
F601# FUSE 4.00A/125V PAGG20CNG402
FH601 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
FH602 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
GP641# GAP. FNR-G3.10D FAZ000LD6005
JC13 CHIP RES.(1608) 1/10W 0 Ω RRXAJR5Z0000
JC14 CHIP RES.(1608) 1/10W 0 Ω RRXAJR5Z0000
JC15 CHIP RES.(1608) 1/10W 0 Ω RRXAJR5Z0000
JC18 CHIP RES.(1608) 1/10W 0 Ω RRXAJR5Z0000
JC702 CHIP RES.(1608) 1/10W 0 Ω RRXAJR5Z0000
JC703 CHIP RES.(1608) 1/10W 0 Ω RRXAJR5Z0000
JC810 CHIP RES.(1608) 1/10W 0 Ω RRXAJR5Z0000
Ref. No. Description Part No.
JK701 JACK RCA PCB L AV1-09-023 JXRL010RP047
JK702 JACK RCA PCB L AV1-09-024 JXRL010RP048
JK703 JACK SW RCA PCB L AV1-09-032 JYRL010RP023
JK711 JACK SW RCA PCB L AV3-19-021 JYRL030RP026
JK721 Y/C JACK 1P(SW) DMDC1-01-021 JYEL040RP001
JK741 JACK RCA PCB L AV3-19-22 JXRL030RP044
JK742 RCA JACK(SW) MSP-213V2-132 NI FE JYRL030LY028
JS572 PCB JUMPER D0.6-P5.0 JW5.0T
JS801 PCB JUMPER D0.6-P5.0 JW5.0T
JS802 PCB JUMPER D0.6-P5.0 JW5.0T
L1 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
LD001 LEAD WIRE TC UL1015 AWG20 01/110/
AWG20/BLUE
WX3601CA5511
PS691# THERMISTOR ZPB45BL3R0A QNBZ45BL3R0A
RCV401 REMOCON RECEIVE UNIT KSM-602SR2E-2 USESJRSKK045
RL601# POWER RELAY SDT-S-112LMR MRNDC12QN014
SA601# SURGE ABSORBER 470V+-10PER NVQZ10D471KB
SF11 FILTER CERAMIC BAND PASS
SAFHS45M7VAJZ00B05
FBB456LMR004
T571# FLYBACK TRANSFORMER JF0501-3301 LTF00CPXB046
T572 HORIZONTAL DRIVE TRANS(PB FREE
PY2005
LTH00CPY2005
T601# SWITCHING TRANSFOMER 5751 LTT00CPKT198
TP601 PCB JUMPER D0.6-P18.5 JW18.5T
TU11 TUNER UNIT TDQU2 UTUNNTUAL048
VR661# CARBON P.O.T. VZ067TL1 B203 PB(F) VRCB203HH014
X301 XTAL 3.579545 MHz FXD355LLN003
Ref. No. Description Part No.
CRT CBA
Consists of the following:
----------
CAPACITORS
C1501 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C1502 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1510 CERAMIC CAP. B K 2200pF/2KV CCD3DKD0B222
C1511 CERAMIC CAP.(AX) B K 220pF/50V CCA1JKT0B221
C1512 CERAMIC CAP.(AX) B 0.01µF/50V CCK1JKT0B103
C1521 CERAMIC CAP.(AX) B K 220pF/50V CCA1JKT0B221
C1522 CERAMIC CAP.(AX) B 0.01µF/50V CCK1JKT0B103
C1531 CERAMIC CAP.(AX) B K 220pF/50V CCA1JKT0B221
C1532 CERAMIC CAP.(AX) B 0.01µF/50V CCK1JKT0B103
CONNECTOR
CN1501 CONNECTOR PIN 1P RT-01N-2.3A 1730688
DIODE
D1501 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
COIL
L1501 INDUCTOR 180µH-J-5FT LLARJCSTU181
TRANSISTORS
Q1511 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q1512 TRANSISTOR 2SC5360 FA Q QQWZC5360FAQ
Q1521 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q1522 TRANSISTOR 2SC5360 FA Q QQWZC5360FAQ
Q1531 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q1532 TRANSISTOR 2SC5360 FA Q QQWZC5360FAQ
RESISTORS
R1501 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R1502 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R1503 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R1510# METAL RESISTOR 3W J 10k Ω RN03103ZU001
R1511 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R1512 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R1514 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
Ref. No. Description Part No.
