LABELS AND SYMBOLS
The PRECISE TOUCH device shows information pertaining
to the device's part number, serial number, manufacturer
information and the electrical and regulatory standards the
PRECISE TOUCH complies with.
This device is not suitable for use in the presence of a
flammable anesthetic mixture with air or with Oxygen or
Nitrous Oxide.
EC REP
mdi Europa GmbH
Langenhagener Str. 71
D-30855 Hannover-Langenhagen
Iluminage Ltd.
Yokneam Illit 2069200, IL
Class
||
equipment
CE Mark
WEEE - Waste Electrical and Electronic
Equipment
Degree of protection against electric
type BF applied part
Do Not use in wet environment
Follow operating instructions
DEFINITION OF SYMBOLS
550-1200 nm
up to 4 J/cm2
6.78 MHz
up to 5W avg.
up to 1 Hz (1 flash every 1 second)
100-240Vac, 0.9Amax, 50-60Hz
4 x 9 x 15 cm (W x L x H)
0.25 kg
Light spectrum
Max optical energy
RF wave frequency
Max radio frequency power
Flash light repetition rate
Electrical rating
Dimensions
Weight
*Patended technology US67028208 - US5405368
PRECISE TOUCH
EN 60335:1 2002 (A1:2004;
A2:2009)
EN 60335-2-27: 2009
IEC 62471:2006
IEC 60601-1, 3rd edition
IEC 60601-1-11
IEC 60601-2-57
ETL CLASSIFIED
CONFORMS TO UL STD.
UL 60601-1 CERT TO CSA STD.
C22.2 No. 601.1
EN 61000-6-1:2007
EN 61000-6-3:2007
IEC 60601-1-2:2007
APPLICABLE STANDARDS
SAFETY STANDARDS EMC STANDARDS
Temperature
Humidity
Pressure
Temperature
Relative Humidity
Altitude
ACCEPTABLE ENVIRONMENTAL CONDITIONS
STORAGE/TRANSPORT OPERATING
14°F - 131°F/ -10°C - 55°C
Up to 90% at 131°F
700-1060 hPa
50°F-86°F/ 10°C-30°C
Up to 80% at 99°F
Up to 13,000ft
PRECISE TOUCH SPECIFICATIONS*
