ILVE BC645 - Dimensions and Label Data; Basic Safety Rules and Positioning

7
G
G
G
B
B
G
B
B
Dimesions
545 mm
438 mm
551 mm
456 mm
598 mm
570 mm
530 mm
670 mm
680 mm
Built-in dimensions Overall dimensions Packaging dimensions
Basic Safety Rules
The user is responsible for operations carried out on the appliance without following the instructions provided
in this manual.
The following are the main safety rules to be observed for the installation:
• disconnect the appliance from the power supply before working on it;
• to disconnect the appliance do not pull the power cable;
• do not touch the appliance with wet or damp hands/feet or without suitable protections (e.g. suitable glo-
ves and shoes);
• do not insert screwdrivers, kitchen utensils or objects between the grids and into moving parts.
Label data
The appliance data are indicated on a label on the side (Fig. 4)
Fig. 4 – Product data label
Note: do not remove, alter, damage or modify the data label.
INSTALLATION
