Burners, Injectors & Mega-joules
AIR ADJUSTMENT
The air adjustment is to be carried out with the flame at the maximum, with a screwdriver loosen screw
“F” and move the cylindrical sleeve “R” towards the injector to decrease the air, move it away from the
injector to increase the air. Once the correct aeration is achieved tighten screw “F” to fix the position.
BURNER NATURAL GAS
Inj Mj/h Kpa
ULPG
Inj Mj/h Kpa
DUAL WOK
1.60/0.68 14/2.2 1.00 0.86/.040 11.5/2 2.75
SINGLE WOK
1.70 13.8 1.00 0.92 11.00 2.75
LARGE
1.40 10.0 1.00 0.82 9.00 2.75
MEDIUM
1.10 6.2 1.00 0.68 6.00 2.75
FISH / TEPANYAKI
1.60 12.5 1.00 0.85 10.00 2.75
