ILVE ILC604B - Description of the Appliance; Technical Characteristics; Control Panel; Use of the Appliance

7
DESCRIPTION OF THE APPLIANCE
Technical characteristics
Type
Total Power
Position of the
heating zone
Diameter
Nominal Power
ILC604B
ILC70B
6000 W
Front left
Rear left
Rear right
Front right
190 mm
155 mm
190 mm
155 mm
1800 W
1200 W
1800 W
1200 W
ILC90B
7000 W
Front left
Rear left
Rear right
Front right
135 / 220 mm
155 mm
190 mm
190 mm
1000 / 2200 W
1200 W
1800 W
1800 W
Control panel
USE OF THE APPLIANCE
Display
Display Designation Function
0 Zero The heating zone is activated.
1…9 Power level Selection of the cooking level.
A Heat accelerator Automatic cooking
E Error message Electronic failure.
H Residual heat The heating zone is hot.
L Locking Control panel locking.
On/Off key
[ + ] key,
selection zone
[ - ] key for all 4
heating zones
Power display
Extension zone
(according on
model)
