Part Identification Chart—Model No. IMBE41991
R1200A
M10 Nylon Locknut (11)—26
M8 Nylon Locknut (54)—11
M6 Washer (30)—5
M8 x 60mm Bolt (39)—2
M6 x 38mm Bolt (60)—1
M6 x 55mm Bolt (4)—4
M8 x 30mm Bolt (38)—2
M8 x 70mm Bolt (41)—4
M10 x 180mm Bolt (22)—2
M10 Washer (6)—14
M10 x 70mm Bolt (46)—8
M10 x 65mm Bolt (42)—4
M10 x 115mm Bolt (55)—1
M10 x 80mm Bolt (56)—1
M8 x 65mm Carriage Bolt (59)—4
M8 x 20mm Screw (50)—2
M10 x 25mm Button Head Bolt (43)—2
M10 x 65mm Carriage Bolt (40)—8
M8 x 80mm Bolt (9)—1
M6 x 16mm Screw (3)—2
M10 x 25mm Bolt (53)—2
M8 Washer (52)—10
