SPECIAL FEATURES
Optimized operating software
iMAX Quattro B6 features the so-called AUTO function that set the feeding current
during the process of charging or discharging. Especially for Lithium batteries, it can
prevent the overcharging which may lead to an explosion due to the user's fault. It can
disconnect the circuit automatically and alarm once detecting any malfunction. All the
programs of this product were controlled through two way linkage and communication,
to achieve the maximum safety and minimize the trouble. All the settings can be
configured by users!
Internal independent lithium battery balancer
iMAX Quattro B6 employs an individual-cell-voltage balancer. It isn't necessary to
connect an external balancer for balance charging.
Balancing individual cells battery discharging
During the process of discharging, iMAX Quattro B6 can monitor and balance each cell
of the battery individually. Error message will be indicated and the process will be ended
automatically if the voltage of any single one cell is abnormal.
Adaptable to various type of lithium battery
IMAX Quattro B6 is adaptable to various types of Lithium batteries, such as Li-ion, LiPo
and the new LiFe series of batteries.
03
INTRODUCTION
Please read this entire operating manual completely and attentively before
using this product, as it covers a wide range of information on operating and
safety. Or please do use this product in company with a specialist!
LCD Screen
Temp. Sensor/PC Link
Available for charger 1 & 2 only
Universal
Balancing Port
Pitch=2.54mm
Battery Sockets
Menu Control Buttons
Twin Ventilation Fan
with Temperature Sensor Control
INPUT
DC 11~15V
02
iMAX Quattro B6 allows you to plug 4 batteries into one charger simultaneously, and it
will intelligently and automatically charge all 4 of them at once to their maximum capacity.
To top of it, the batteries being charged do not even need to have the same configuration.
You can connect different chemistry Ni-MH/Ni-CD/LiPo/LiFe batteries into any of the
charging ports. No more staying up late for charging batteries.
