IMC 723 User Manual

700/800 Series Food Waste Disposer 11
PARTS LIST
723
Item Part No Description Item Part No Description
1 E60/021 Flange Plate Assembly 8 J03/134 Ball valve / Strainer
2 A11/250 Gasket 9 S60/016 Release Key
3 D25/008 Washer M6 10 E60/019 Sink Inlet Assembly
D25/005 Washer M6 Shakeproof
D20/013 Full Nut M6 11 J04/319 Trough Inlet
D19/115 Screw M6
12 E60/022 Torque Bar
4 C60/001M1 Interface Casting
13 E10/019 Silver Saver (Optional)
5 E60/016 Baffle Welded Assembly
14 G30/353 Starter Box 230-1-50
6 G40/157 Motor 1.1kW 230-1-50 G30/350 Starter Box 400-3-50 4 Wire
G40/158 Motor 1.1kW 400-3-50
C23/010M1 Top Housing
D20/039 M10 Philidas Nut
D19/091 M10 x 30 Hex Head Screw
D25/010 M10 Plain Washer
C23/011M Rotor
A02/047 Speedi Sleeve
C13/005M1 Cutter ring
D19/044 M8 x 16 Hex Head Screw
D25/070 Nylon Washer
L32/067 Washer
D25/041 Fibre Washer
A02/048 Seal
E30/102 Rotor Flinger
E30/103 Flinger Baffle
L32/064 Rotor Spacer
A11/162 Motor Shield Gasket
A00/148 Bearing
D23/023 Stud
D25/012 M8 Seloc Washer
D20/023 M8 Full Nut
L54/001 Dowell Pin
A11/145 Hopper gasket
A11/098 Waste Outlet Gasket
C23/004M1Z Waste Outlet
D19/097 M6 x 30 Hex Head Screw
7 S60/013 Solenoid 230V (1ph)
S60/006 Solenoid 400V (4 wire 3ph)
J04/073 Straight Coupler
When ordering spare parts or accessories always quote the SERIES
NUMBER of the machine, found on the rating label.
