IMC 723 User Manual

12 700/800 Series Food Waste Disposer
725 & 726 Series.
Item Part No Description Item Part No Description
1 E60/001 Frame – 726 5 S60/004 Solenoid 230V (1ph & 5 wire 3ph)
A10/481 Adjustable Foot S60/003 Solenoid 400V (4 wire 3ph)
A13/054 Square Foot J04/073 Straight Coupler
J01/080 Copper Pipe
2 E60/001 Hopper - 725 J03/134 Ball valve / Strainer
E60/009 Hopper & Top - 726 J04/130 Elbow
D19/031 M5 x 10 Hex Head Screw
D25/021 M5 Plain Washer 6 E68/007 Front Panel – 726
D25/004 M5 Shakeproof Washer D19/031 M5 x 10 Hex Head Screw
D25/021 M5 Plain Washer
3 E60/004 Baffle D25/004 M5 Shakeproof Washer
A31/002 Magnet
D21/043 M5 x 10 Pan Head Screw 7 G45/053 Switch Interlock
D25/004 M5 Shakeproof Washer D21/047 M5 x 25 Pan Head Screw
M68 Interlock Body D25/004 M5 Shakeproof Washer
M69 Interlock Knob
M48 Interlock Plug 8 G76/021 Terminal Box
D26/017 Pin D21/101 M4 x 10 Pan Head Screw
4 G40/157 Motor 1.1kW 230-1-50 9 G30/353 Starter Box 230-1-50
G40/158 Motor 1.1kW 400-3-50 G30/350 Starter Box 400-3-50 4 Wire
C23/010M1 Top Housing G30/351 Starter Box 400-3-50 5 Wire
D20/039 M10 Philidas Nut E60/007 Back Plate – 726
D19/091 M10 x 30 Hex Head Screw A10/134 Blind Grommet
D25/010 M10 Plain Washer A11/177 Sponge Washer – 726
C23/011M Rotor
A02/047 Speedi Sleeve OPTIONAL ITEMS
C13/005M1 Cutter ring
D19/044 M8 x 16 Hex Head Screw E60/010 Side panel - 726
D25/070 Nylon Washer
L32/067 Washer
D25/041 Fibre Washer
A02/048 Seal
E30/102 Rotor Flinger
E30/103 Flinger Baffle
L32/064 Rotor Spacer
A11/162 Motor Shield Gasket
A00/148 Bearing
D23/023 Stud
D25/012 M8 Seloc Washer
D20/023 M8 Full Nut
L54/001 Dowell Pin
A11/145 Hopper gasket
A11/098 Waste Outlet Gasket
C23/004M1Z Waste Outlet
D19/097 M6 x 30 Hex Head Screw
When ordering spare parts or accessories always quote the SERIES
NUMBER of the machine, found on the rating label.
