IMER INTERNATIONAL S.p.A.
KOINE 35
TAV. 2 - S TRU TT URA IMP IAN TO AC QU A - STRUCTURE MAC HINE - MAC HINE STR U CTURE - MASCHINEN AUFB AU - E STR U CTU RA DE LA MAQU INA
Rif. Cod. I F GB D E Note
13223619 NIPPLO MAMELON GREASE NIPPLE NIPPEL NIPLE
M.M. 1" 1/2
OTTONE
23224207 POMPA ACQUA POMPE EAU WATER PUMP WASSERPUMPE BOMBA DE AGUA NGXm2
33223617 RACCORDO RACCORD CONNECTOR ANSCHLUSS EMPALME
F.F.F. 1 /2 "1/2"1/2 "
OTTONE
43223630 PRESSOSTATO PRESSOSTAT PRESSURE SWITCH DRUCKSCHALTER PRESOSTATO
GP600
1/4 Gc 1-5 BAR
53223609 RIDUZIONE RÉDUCTION REDUCTION REDUZIERSTÜCK REDUCCIÓN
M.1/2"-F.1/4"
OTTONE
63223606 RACCORDO RACCORD CONNECTOR ANSCHLUSS EMPALME
F.F.F.F.
1/2"1/2"1/2"1/2"
OTTONE
73223611 TRONCHETTO TRICOISES BRANCH BOLZEN MANGUITO
M.1/2" L =125
OTTONE
83223625 MANOMETRO MANOMÈTRE PRESSURE GAUGE MANOMETER MANÓMETRO
10 BAR 1/4"
CONICO D.63
ATT.POSTERIORE
93224176CALOTTA IN GOMMA
CALOTTE EN
CAOUTCHOUC
RUBBER COVER GUMMIHAUBE CASQUETE DE GOMA
D.63 CON
ATTACCO POST.
10 3223959 NIPPLO MAMELON GREASE NIPPLE NIPPEL NIPLE
1/8" M.M. CONICO
OTTONE
11 3223620 VALV OLA SFERICA MINI
SOUPAPE SPHÉRIQUE
MINI
MINI BALL VALVE MINI-KUGELVENTIL
VÁLVULA ESFÉRICA
MINI
F/F CIL.1/8"
NICHELATA
12 3223632 TRONCHETTO TRICOISES BRANCH BOLZEN MANGUITO
M. 1/2" L=50
OTTONE
13 3223618 BOCCHETTONE GOULOTTE INL E T STUTZEN BOCA
M.F. SEDE CONICA
1/2" OTTONE
14 3224170 NIPPLO MAMELON GREASE NIPPLE NIPPEL NIPLE M.M. 1" 3/4 GHISA
15 3224171 CURVA 45° COUDE 45° 45° BEND 45°-KURVE CURVA 45° 3/4" M.F. GHISA
16 3223636 ATTACCO RAPIDO FIXATION RAPIDE QUICK CONNECTOR SCHNELLANSCHLUSS EMPALME RÁPIDO
FEMM. 3/4"
OTTONE
17 3223957 TRONCHETTO TRICOISES BRANCH BOLZEN MANGUITO
M. 1/2" L=85
OTTONE
18 3224168 GOMITO 90° COUDE 90° 90° ELBOW FITTING 90°-KURVE CODO 90° 1/2" F.F. OTTONE
19 3223627 VALVOLA ANGOLO SOUPAPE ANGULAIRE ANGLE VALVE WINKELVENTIL VÁLVULA ÁNGULO
REG.MICR.1/2" SYR
ART. PFT n°1577
20 3223629
RIDUTTORE DI
PRESSIONE
RÉDUCTEUR DE
PRESSION
PRESSURE REDUCER DRUCKMINDERER
REDUCTOR DE
PRESIÓN
DO6F-1/2" ZPI
21 3223624 RACCORDO ARIA RACCORD AIR AIR CONNECTOR LUFTANSCHLUSS EMPALME DEL AIRE
90° GIREV.1/4"CIL.
CON OR
22 3223626 MANOMETRO MANOMÈTRE PRESSURE GAUGE MANOMETER MANÓMETRO
4 BAR 1/4" CONICO
D.63 ATT.RADIALE
23 3228388 ELETTROVALVOLA ÉLECTROVANNE SOLENOID VALVE MAGNETVENTIL ELECTROVÁLVULA
L182-B ZB10A
24V 50/60 Hz
24 3223729 PROTEZIONE POMPA PROTECTION POMPE PUMP PROTECTION PUMPENSCHUTZ
PROTECCIÓN DE LA
BOMBA
25 3223637 GOMITO 90° COUDE 90° 90° ELBOW FITTING 90°-KURVE CODO 90°
M.F. CON
BOCC.SEDE
CONICA 1/2"
OTTONE
26 3223613 PORTAGOMMA PORTE-CAOUTCHOUC HOSE FITTING SCHLAUCHHALTER ADAPTADOR M1/2"x13 OTTONE
27 3223634 TUBO ACQUA TUYAU EAU WATER HOSE WASSERSCHLAUCH TUBO DE AGUA D.13 15 BAR L=500
28 3223638 FASCETTA AD ANELLO
COLLIER EN FORME DE
BAGUE
RING CLIP RINGSCHELLE
ABRAZADERA DE
ANILLO
D.20-30
29 3223612 TAPPO MASCHIO BOUCHON MÂLE MALE PLUG
STUTZEN MIT
AUSSENGEWINDE
TA P ÓN M A C HO M.3 /8 " O T TONE
30 1272701 TUBO TUYAU HOSE LEITUNG TUBO D8/6 L=400
31 3223616 RACCORDO RACCORD CONNECTOR ANSCHLUSS EMPALME
F
.F.F. 3/8"3/8"3/8"
OTTONE
32 3223610 TA P P O BOUCHON PLUG STUTZEN TA P ÓN M.1/2" OTTONE
33 3223623 RACCORDO ARIA RACCORDO AIR AIR CONNECTOR LUFTANSCHLUSS EMPALME DEL AIRE
M. CONICO 3/8"
ZINCATO
34 3223621 VALVOLA SFERICA SOUPAPE SPHÉRIQUE BALL VALVE KUGELVENTIL VÁLVULA ESFÉRICA
F/M CIL.3/8"
NICHELATA
35 3223633 FLUSSIMETRO FLUXMÈTRE FLOW METER DURCHFLUSSMESSER CAUDALIMETRO
1/2"150-1500 L/h
TROGLAMIO
36 3223607 NIPPLO MAMELON GREASE NIPPLE NIPPEL NIPLE 1/2" OTTONE
37 3223730 GHIERA FLANGIATA FRETTE BRIDÉE FLANGED RINGNUT FLANSCHNUT
VIROLA CON ARANDELA
NICHELATA 1/2"
38 3223622 VALVOLA SFERICA SOUPAPE SPHÉRIQUE BALL VALVE KUGELVENTIL VÁLVULA ESFÉRICA
F/M CIL.1/2"
NICHELATA
39 3223958 TRONCHETTO TRICOISES BRANCH BOLZEN MANGUITO
M.1/2" L=70
OTTONE
40 3223639 FILTRO FILTRE FILTER FILTER FILTRO
41 3223615 ATTACCO RAPIDO FIXATION RAPIDE QUICK CONNECTOR SCHNELLANSCHLUSS EMPALME RÁPIDO
CON PORTAG. D.13
OTTONE
42 3223635 TUBO ACQUA TUYAU EAU WATER HOSE WASSERSCHLAUCH TUBO DE AGUA D.13 15 BAR L=400
43 3224169 PORTAGOMMA PORTE-CAOUTCHOUC HOSE FITTING SCHLAUCHHALTER ADAPTADOR F. 1/2"x13 OTTONE
44 3223721 ATTACCO A CAMME FIXATION À CAMES CAM COUPLING NOCKENANSCHLUSS EMPALME DE LEVAS DN 25 M. 1" G. F.
45 3223722 ATTACCO RAPIDO FIXATION RAPIDE CK CONNECTOR SCHNELLANSCHLUSS EMPALME RÁPIDO 1" M. OTTONE
46 3226729 FILTRO FILTRE FILTER FILTER FILTRO
47 3223697
GUARNIZIONE ATTACCO
RAPIDO
JOINT RACCORD
RAPIDE
SEAL QUIK COUPLING DICHTUNG
GUARNICIÓN CONEXIN
RÁPIDA
NOTA: L' unità di misura della lunghezza, indicata con L=, è da considerarsi in mm
REMARQUE : l'unite de mesure de la longueur indiquee par L=, est en mm
NOTE: The unit of measurement for length, indicated with L=, is expressed in mm
HINWEIS: Die Längenmaße L= sind in mm angegeben
NOTA: la unidad de medida (L=) se expresa en mm
