MINUTEMAN
DIAGRAM #2 MOTOR AND GEARBOX ASSEMBLY
COD. 3210492 (110 / 115 V - 60 Hz)
UP TO SERIAL
NUMBER:
RIF. P.n. Description Note
1 2222010 BOLT M6x25
2 2207405 OIL SEAL 55x40x10
3 2222012 BOLT M6x60
4 3210485 GEARBOX CASE-HALF
5 3210482 GEARBOX GASKET
6 2228360 SHEAR PIN Ø8x16
7 2229500 KEY 8x7x15
8 2204420 BEARING 6201
9 3210487 GEAR Z 81
10 2229249 KEY 5x5x12
11 3210483 PINION GEAR Z 9
12 3210486 GEARBOX CASE-HALF
13 3210904 FAN
14 3210911 ELECTRIC BOX COMPLETE (ALL COMPONENTS)
1005797 15 3210233 SWITCH
16 3210955 ELECTRICAL PLUG
19 3210923 CAPACITOR 50µF 250 V
1005797 20 3233039 ELECTRIC BOX ASS'Y + SCREW + GASKET ONLY
21 3209214 GASKET
22 2223260 NUT M6
23 2224530 WASHER Ø6x12.5
24 2204550 BEARING 6205
25 3210479 GEAR Z 104
26 2204504 BEARING 6008
27 2228819 LOCATING PIN Ø6x12
28 3210494 MOTOR ASS'Y WITH CASE HALF
29 3210481 DRIVE SHAFT SPINDLE
30 3210496 RIGHT SIDE MOTOR COVER
31 3210495 LEFT SIDE MOTOR COVER
32 3210036 SCREW M5x16
33 3210587 RATING PLATE
35 3210906 STATOR
36 3210898 SPACER WASHER
37 3210486 ROTOR
38 3210901 SCREW M5x22
39 3208982 BEARING 6202
40 3210488 INSULATING FLANGE
41 2207350 OIL SEAL 12x32x7
42 3210902 BEARING 6002
