IMER U.S.A. Inc.
4
MINUTEMAN
Product development and improvement is an ongoing process, therefore, specifications may change
without notice.
* Capacities based on usable volume.
TECHNICAL DATA
1 MIXING DRUM 5 GEARBOX MOUNTING FRAME
2 ON/OFF SWITCH 6 SWIVEL BRACKET
3 DUMP HANDLE 7 MAIN FRAME
4 MOTOR AND GEARBOX DRIVE 8 T-BAR
Drum capacity 5 cubic feet
Batch Output 2.5 cubic feet, 225 lbs. *
Drum Diameter 24 inches
Discharge outlet height 23 inches
Wheels 12" x 2.5"
Single Phase electric motor 0.5 HP
Voltage 110 / 115 V
Hertz 60
Motor R.P.M. 3350
Nominal current 6.2 Amp
Operating dimensions 42" x 25" x 58"
Storage dimensions 25" x 25" x 25.5"
Weight 120 pounds
