IMER U.S.A. Inc.
COMBI 250 VA
9
TAV. 1 - MACHINE STRUCTURE
REF. CODE DESCRIPTION NOTES
1 3210055 TANK
2 3226064 R.H. SURFACE
3 3226265 L.H. SURFACE
4 3226070 REAR SIDE
5 3226069 FRONT SIDE
6 3226359 REAR ARM
7 3226357 FRONT ARM
8 3234381 SLIDEWAY
9 3226073 RIGHT FENCE
10 3226074 LEFT FENCE
11 3210071 T-NUT
12 3210099 BOLT TEFR 6X25
13 3210576 WASHER D.8,4X17X1,5
14 2235429 CAP
15 2222545 BOLT TCEI 5931 M6X30
16 3204865 KNOB M6
17 3226087 WASHER D.10,5X17X1,5
18 3226088 BUSHING
19 2223920 NUT 7474 M10
20 3226747 BOLT TTDE 5732 8X40
21 3210069 MILLIMETRED STRIP
22 2284866 KNOB M8
23 2222584 BOLT TSPEI 5933 M6X25
24 3210070 ROD
25 3226083 BRACKET
26 2222449 BOLT TC 6954 3.5X19
