IMER STEP 120 - Page 72

72
IMER INTERNATIONAL S.p.A.
STEP 120
TAV.4 COMPRESSORE 220V - COMPRESSEUR 220V - COMPRESSOR 220V - VERDICHTER 220V - COMPRESOR 220
DA MATRICOLA
DE NOMBRE SÉRIE
UP TO SERIAL
NUMBER
DE NUMERO DE
SERIE
Rif. Cod. I F GB D E Note
1
3226271
PIASTRA SUPPORTO
COMPRESSORE
PLAQUE DE SUPPORT
COMPRESSEUR
COMPRESSOR PLATE
SUPPORT
VERDICHTERPLATTE
LAGER
PLACA BASE COMPRE-
SOR
2 3226273
SUPPORTO QUADRO
ELETTRICO
SUPPORT TBLEAU
ELECTRIQUE
ELECTRICAL PANNEL
SUPPORT
LAGER SCHALTTAFEL
BASE CUADRO ELÉC-
TRICO
3
3226864 ANTIVIBRANTE
SUPPORT ANTIVIBRA-
TILE
VIBRATION DAMPER
SCHWINGUNGS-
DÄMPFER
ANTIVIBRADOR
M8X20
4 3223630 PRESSOSTATO PRESSOSTAT PRESSURE SWITCH DRUCHSCHALTER PRESOSTATO
GP600 1/4" CILIN-
DRICO 1-5BAR
5 3224928 NIPLES RIDOTTO NIPLES REDUIT REDUCED NIPPLE
NIPPLE REDUZIER-
STÜCK
NIPLE REDUCTOR
1/2"-3/8" CONICO
GHISA Z
6 3224593 VALVOLA DI SICUREZZA
SOUPAPE DE
SOURPRESSION
RELIEF VALVE
DRUCKBREGENZUNGS-
VENTIL
VALVULA DE MAXIMA
7 3223617 RACCORDO "T" RACCORD COUPLING VERBINDDUNGSDTCK RACOR
T 1/2" F.F.F.
8 3223609 RIDUZIONE RÉDUCTION REDUCER REDUZIERSTÜCK REDUCCIÓN
M. 1/2" F.1/4"
OTTONE
9 3223613 PORTAGOMMA EMBOUT DE TUYAU AIR HOSE CLAMP SCHLAUCHHALTER
NIPLES
M.1/2"X13
10 3224345 RACCORDO ARIA 90° RACCORD COUPLING VERBINDDUNGSDTCK
RACOR GIREV.INN.RAPID.
1/4" PER TUBO 8/6
11 3224362 NIPLES NIPLES REDUCED NIPPLE
NIPLE
1/2"
12 3224608 TUBO AIR WATER TUYAU HOSE SCHLAUCH
MANGUERA 13X20 20BAR
L.170mm
13 3224360 VALVOLA DI RITENUTA
SOUPAPE DE
SOURPRESSION
RELIEF VALVE
DRUCKBREGENZUNGS-
VENTIL
VALVULA DE MAXIMA 1/2" F.F.
14 3223618 BOCCHETTONE EMBOUT CAP KAPPE BOCA
M.F A SEDE CCO-
NICA 1/2"
15 3225126 TAPPO OLEODINAMICO BOUCHON M. PLUG M. VERSCHLUSS M. TAPON M.
1/4" CILINDRICO
SV. 60°
3007466 16 3229670 QUADRO ELETTRICO TBLEAU ELECTRIQUE ELECTRICAL PANNEL SCHALTTAFEL CUADRO EL CTRICO
230V 50HZ
17 3225843 PRESSOSTATO PRESSOSTAT PRESSURE SWITCH DRUCHSCHALTER PRESOSTATO MIGNON 4 VIE 1/4"
18 3224581
RONDELLA SPECIALE
IN NYLON
RONDELLE NYLON NYLON WASHER
UNTERLEGSCHEIBE
NYLON
ARANDELA NYLON
19 3225073
FASCETTA STRINGI-
TUBO
COLLIER CLAMP SCHELLE ABRAZADERA D.17-20
3003406 20 3223884 RACCORDO ARIA 90° RACCORD COUPLING VERBINDDUNGSDTCK RACOR
GIREV.INN.RAPID.
1/4" CONICO PER
TUBO 8/6
3003406 21 3227964
DISTRIBUZIONE A "T"
1/2"
RÉPARTITION "T" 1/2" DISTRIBUTION "T" 1/2" VERBREITUNG "T" 1/2" DISTRIBUCIÓN "T" 1/2"
22 1272701 TUBO ARIA TUYAU HOSE SCHLAUCH MANGUERA D.8/6 L.40CM
3003406 23 3226816 TUBO ARIA TUYAU HOSE SCHLAUCH MANGUERA D.6/4 L.40Cm
24 3224608 TUBO AIR WATER TUYAU HOSE SCHLAUCH MANGUERA
20 BAR 13X20
L.1200 mm
25 3223697
GUARNIZIONE ATTACCO
RAPIDO
JOINT DE RACCORD
EXCENTRI UE
QUICK COUPLING
GASKET
DICHTUNG SCHNEL-
LKUPPLER
JUNTA CONEXIÓN
RÁPIDA
26 3224203 ATTACCO RAPIDO RACCORD RAPIDE QUICK CONNECTOR SCHNELLVERBINDUNG EMPALME RAPIDO
1/2"M.
27 3224202 VALVOLA SFERA BOISSEAU SPHERIQUE BALL VALVE KUGELVENTIL VÁLVULA ESFERA
1/2" F.F.
28 3223957
TRONCHETTO FILET-
TATO
EMBOUT DE TUBE
FILETE
THREADED BRANCH GEWINDESTUTZEN VÁSTAGO ROSCADO
M 1/2" L.85MM
OTTONE
29 3223730 GHIERA FLANGIATA FRETTE NICKELEE
NICKEL-PLATED FLAN-
GED RING NUTA
FLANSCHNUT VERNI-
CKELT
VIROLA EMBRIDADA
NIQUELADA
NICHELATA 1/2"
30 3224205
CURVA AMPIO RAGGIO
45°
COUDE GRAND RAYON WIDE RADIUS BEND GROSSE KURVE CURVA AMPLIO RADIO
1/2" F.F.
31 3234995 KIT VENTILAZIONE
KIT REFROIDISSEMENT COOLING KIT KIT AUSSENKÜHLUNG KIT ENFRIAMIENTO
