1903KITINT18_230 – 1903KITINT18_400 (E121001A_ENG) 26/10/2012
2
INDEX:
1. INTRODUCTION ................................ 2
2. SAFETY RULES................................. 2
3. MANUFACTURER LIABILITY ........... 3
4. KIT ..................................................... 3
5. INSTALLATION - MECHANIC ........... 3
6. INSTALLATION - ELECTRIC
COMPONENTS ...................................... 5
7. WORKING TEST ................................ 6
8. THERMAL MOTOR ADJUSTMENT ... 6
1. INTRODUCTION
Thi kit can be installed only on tumble
dryers model ES10/14/18 which are not
yet equipped with the reversing drum
option.
These instructions explains in detail how
to separate the drum rotation from the fan
rotation.
This kit can be installed both in 3x220
[V~] and 3x400/440 [V~] electric system
with or without Neutral.
This kit is necessary when the linen
drying is uneven. This situation can
happen with the biggest linen when the
drum turn in only one sense. In this case
the linen forms a ball and, at the end of
the cycle, it results dried on the external,
wet inside.
The right and left alternated rotation
allows to obtain a more homogenous and
quick drying.
This manual is written in compliance with
the European Regulation in force.
The information here written are
addressed to the service technician, who
must be sure to fully understand them
before to operate on the machine.
These instructions must always be able
available for consultancy.
In case this document would be missed
or damaged, please ask for a new copy to
the manufacturer.
The manufacture is not responsible for
consequences coming from a not correct
use of the new device, nor for
consequences coming from the
misreading or not complete reading of
this document.
The manufacturer reserves itself the right
to modify the characteristics of the device
here described.
Pictures of this manual may differs from
the part really mounted on the machine.
Diagram and technical data may be
modified without any previous notice.
Manual and its annex are part themselves
of the machine, so they must be stored
and they must follow the machine in case
of sale.
2. SAFETY RULES
Ignoring the following safety precautions
can cause damage either to people, linen,
animals or to the machine.
Installation and maintenance of the here
described machine must be trained only
by authorized personnel.
The here described tumble dryer can be
used only for the professional drying of
garments and linen: any other use is
forbidden if not previously authorized in
written by the manufacturer.
To avoid any risks of fire or explosion, do
not approach the machine with
combustible or flammable products
Always stick to the drying instructions
sewed to each item.
The machine used is forbidden to people
younger then 14 years.
Supplementary connection to the
machine, if not duly performed, are
releasing the manufacturer from any
responsibility.
