29
INSTALLERUSER
MAINTENANCE TECHNICIAN
3.6 PROGRAMMING.
The water heater is set up for possible pro-
gramming of several operation parameters.
By modifying these parameters as described
below, the system can be adapted according to
specic needs.
Menù Service
Menu item Description Range
Denition of Zone Zone system sub-menu settings -
Dening plant Sub-menu to dene the devices connected to the system -
Device conguration Sub-menu to set the device's conguration -
ermoreg. heat Central heating thermoregulation setting sub-menu -
ermoreg. cool Cooling thermoregulation setting sub-menu -
ermoreg. parameters Parameters thermoregulation setting sub-menu -
Integration System integration setting sub-menu -
Heat pump Heat pump operating parameters sub-menu -
Manual Manual operating parameters sub-menu -
Factory settings Default settings restore sub-menu -
Menù Service -> Denition of Zone
Menu item Description Range Default
Customised
value
Mode Display the operating mode - Hot + Cold -
Enable remote control
Enable operation of the supplied remote control.
If “No” is set, the remote panel only displays the heat pump statuses.
N.B.: setting “No”, it is compulsory to enable the room thermostat (re-
fer to the next item), otherwise the machine will display an anomaly.
Yes / No Yes
Enable thermostat
Enable operation of a room thermostat to check the heat pump
PdC is controlled by contacts in the said P.C.B.
Yes / No No
Enable dew point Enable operation with a humidity probe in the remote panel. Yes / No Yes
Menù Service -> Dening plant
Menu item Description Range Default
Customised
value
External probe Enables operation with the external probe. No / PdC No
Reduction function
Enable PdC operation frequency reduction, which is controlled by the
said terminal board.
Yes / No No
Menù Service -> Device conguration
Menu item Description Range Default
Customised
value
H.P. control
Setting “Yes”, the default remote control supplied manages the heat
pump.
Setting “No”, the remote control does not control the heat pump and
must be coupled with other Immergas systems (for example, Trio,
Magis Hercules). If “No” is set, it displays another item “slave address”.
N.B.: if it is erroneously set to “No”, it is still possible to change the
selection.
Yes / No Yes
Slave address
Address to congure according to the zone where the device is in-
stalled (e.g.: zone 1 = 41, zone 2 = 42, zone 3 = 43, etc...).
1 ÷ 247 -
Access the “Assistenza” (Assistance) menu by
pressing the right “Menu” button and turning
the main switch until selecting the desired menu.
Press the main switch to conrm the selection.
Insert the relative access code and customise
the parameters according to your requirements.
