Immergas Magis Combo Series User Manual

8
R13
R12
R11 R10
U05
R17
R16
R15 R14
U06
Set Risc
U01
Z1
Z2
Set Raresc
U02
Z2
Z1
R04
R05
R02 R03
U03
R08
R09
R06 R07
U04
10
INSTALLERUSERMAINTENANCE TECHNICIAN
Zone 1 ow temperature in central heating mode, with
external probe
Zone 1 ow temperature in cooling mode, with exter-
nal probe
Flow temperature in central heating mode without
external probe
Flow temperature in cooling mode without external
probe
Zone 2 mixed ow temperature in central heating
mode, with external probe
Zone 2 mixed ow temperature in cooling mode, with
external probe
Key:
Rxx - "Heat regulation" menu parameter
TE - Outside temperature
TM - Flow temperature
U01 - Zone 2 ow temperature in "User" menu central
heating mode
U02 - Zone 2 ow temperature in "User" menu cooling
mode
U03÷06 - Oset value compared to the curve set by the
external probe
Zx - Heating system zone
1.10 HEAT REGULATION SETTING.
By setting the parameters in the "Heat regulation"
menu, you can adjust how the system operates.
e curves (Fig. 8) show the default settings in
the various operating modes available both with
external probe and without.
Attention: in case of use of the CAR
V2
, the heat
adjustment curves, in the central heating phase
only, are determined by the device itself.
Attention: parameters R04, R05, R08, R09, R12,
R13, R16, R17 also serve to dene heating and
cooling temperature ranges without thermal
regulation.
