Immergas MAGIS COMBO - 2.6 PARAMETERS AND INFORMATION MENU.; Data Menu.

29
INSTALLERUSERMAINTENANCE TECHNICIAN
2.6 PARAMETERS AND INFORMATION
MENU.
Pressing the "MENU" button (2), the display
cyclically shows the "Data" menu, "User" menu
and a menu protected by a "0000" access code
with the rst ashing digit reserved for a qualied
technician.
Id
Parameter
Description Range
D 01 Combustion signal ( x 0,1 µA) 0 ÷ 99 µA
D 02 Temperature of the instant heating thermal generator ow outgoing from the heat generator primary exchanger 0 ÷ 99 °C
D 03 Instant output temperature from the DHW exchanger 0 ÷ 99 °C
D 04 Value calculated for system setting 7 ÷ 80 °C
D 05 Value set for DHW setting 10 ÷ 65 °C
D 06
Outdoor temperature (if the condensing unit external probe is connected or if the optional external probe is availa-
ble)
- 20 ÷ 50 °C
D 07 DHW inlet probe temperature‘ 0 ÷ 99 °C
D 08 Heat pump return water temperature 0 ÷ 99 °C
D 09
List of the last ve anomalies.
(to scroll through the list, press the "OK" button (1))
-
D 10 Anomaly list reset. Once displayed “D 10” press the button “OK”. -
D 12 Heat generator pump operating speed 0 ÷ 100 %
D 13 DHW request presence (not used for this model) OFF - ON
D 14 Heat pump circuit ow rate 0 ÷ 9999 l/h
D 15 Fan operating speed 0 ÷ 9999 rpm
D 20 Heat pump instantaneous ow temperature 0 ÷ 99 °C
D 22 Heat generator 3-way (DHW = domestic hot water, CH = central heating) DHW - CH
D 23 Heat generator return water temperature 0 ÷ 99 °C
D 24 Chiller circuit liquid phase temperature -20 ÷ 99 °C
D 25 Zone 2 ow temperature (if congured) 0 ÷ 99 °C
D 26 Probe for primary accumulation (puer) 0 ÷ 99 °C
D 27 Primary circuit pressure switch OFF - ON
D 28 Heat pump circulator DHW speed 0 ÷ 100 %
D 29 Not used -
D 33 DHW Integration 3-way (not used on this model) OFF - ON
D 34 Heat pump disabling OFF - ON
D 35 Solar system inlet OFF - ON
D 36 Not used -
D 41 Zone 1 relative humidity (if zone 1 humidity sensor active) 0 ÷ 99 %
D 42 Zone 2 relative humidity (if zone 2 humidity sensor active) 0 ÷ 99 %
D 43 Zone 1 humidistat (if zone 1 humidistat active) OFF - ON
D 44 Zone 2 humidistat (if zone 2 humidistat active) OFF - ON
D 45 Dehumidier zone 1 OFF - ON
D 46 Dehumidier zone 2 OFF - ON
D 47 Zone 1 circulator pump OFF - ON
D 48 Zone 2 circulator pump OFF - ON
D 49 Heating (HT) / cooling (CL) system separation 3-way CL - HT
D 51 Zone 1 remote control OFF - ON
D 52 Zone 2 remote control OFF - ON
D 53 System setting with remote connection in zone 1 0 ÷ 99 °C
D 54 System setting with remote connection in zone 2 0 ÷ 99 °C
D 55 Zone 1 thermostat OFF - ON
D 56 Zone 2 thermostat OFF - ON
D 61 System model denition (MP = Magis Pro; MC = Magis Combo; MCP = Magis Combo Plus) MP - MC - MCP
D 62 Communication with outdoor condensing unit OFF - ON
D 63 Communication with other Immergas devices OFF - ON
D 71 Condensing unit operating frequency 0 ÷ 150 Hz
D 72 Condensing unit compressor temperature -20 ÷ 200 °C
D 73 Compressor outlet instantaneous temperature -20 ÷ 100 °C
D 74 Evaporator coil temperature -20 ÷ 100 °C
D 75 Condensing unit compressor absorption 0 ÷ 10 A
D 76 Condensing unit fan speed 0 ÷ 100 rpm
D 77 Electronic expansion valve position 0 ÷ 500
To access an individual menu, once it appears,
press the "OK" button (1).
To scroll through the menu items and to edit the
values, use the heating temperature control but-
tons (5). Pressing the “OK” button (1) conrms
the parameter, while pressing the “ESC” button
(3) goes back to the previous menu or exits.
A minute aer the last operation, the system
automatically exits any of the menus.
Data Menu.
