Immergas MAGIS COMBO - Page 39

39
INSTALLERUSERMAINTENANCE TECHNICIAN
Id
Parameter
Parameter Description Range Default
Customised
value
T 21
Screed heating -
days at minimum
temperature
Denes the time spent at minimum operating temperature during the
active function
0 ÷ 7
days
3
T 22
Screed heating -
ascent gradient
Denes the ascent gradient of the temperature
0 ÷ 30
°C / day
30
T 23
Screed heating -
days at maximum
temperature
Denes the time spent at maximum operating temperature during the
active function
0 ÷ 14
days
4
T 24
Screed heating -
descent gradient
Denes the descent gradient of the temperature
0 ÷ 30
°C / day
30
Heat regulation menu.
Id
Parameter
Parameter Description Range Default
Customised
value
R 01 External probe
Denes if and which external probe is used to manage the system.
OFF = no external probe used
OU = external probe on the condensing unit
IU = optional external probe connected to the hydronic module
OFF - OU
- IU
OU
R 02
Outdoor temper-
ature for max CH
ow Zone 1.
Establishes the outdoor temperature at which to have the maximum ow
temperature of zone 1.
-15 ÷ 25 °C -5
R 03
Outdoor temper-
ature for min CH
ow Zone 1.
Establishes the outdoor temperature at which to have the minimum ow
temperature of zone 1.
-15 ÷ 25 °C 25
R 04
Zone 1 maxi-
mum central
heating.
Denes the maximum ow temperature in zone 1 room central heating
mode.
20 ÷ 80 55
R 05
Zone 1 minimum
central heating.
Denes the minimum ow temperature in zone 1 room central heating
mode.
20 ÷ 80 25
R 06
Outdoor temper-
ature for Zone 2
low temperature
zone max. CH
ow.
Establishes the outdoor temperature at which to have the maximum ow
temperature of zone 2.
-15 ÷ 25 °C -5
R 07
Outdoor temper-
ature for Zone 2
low temperature
zone min. CH
ow.
Establishes the outdoor temperature at which to have the minimum ow
temperature of zone 2.
-15 ÷ 25 °C 25
R 08
Zone 2 low
temperature
zone maximum
central heating.
Denes the maximum ow temperature in zone 2 room central heating
mode.
20 ÷ 80 45
R 09
Zone 2 low
temperature zone
minimum central
heating.
Denes the minimum ow temperature in zone 2 room central heating
mode.
20 ÷ 80 25
R 10
Zone 1 outdoor
temperature
for minimum
cooling ow.
Establishes the maximum outdoor temperature at which to have the mini-
mum ow temperature in zone 1 cooling mode.
20 ÷ 40 35
R 11
Outdoor temper-
ature for Zone
1 maximum
cooling ow.
Establishes the minimum outdoor temperature at which to have the maxi-
mum ow temperature in zone 1 cooling mode.
20 ÷ 40 25
R 12
Zone 1 minimum
cooling.
Denes the minimum ow temperature in zone 1 room cooling mode. 7 ÷ 20 7
R 13
Zone 1 maxi-
mum cooling.
Denes the maximum ow temperature in zone 1 room cooling mode. 7 ÷ 25 12
