40
INSTALLERUSERMAINTENANCE TECHNICIAN
Id
Parameter
Parameter Description Range Default
Customised
value
R 14
Outdoor temper-
ature for Zone 2
low temperature
zone min cooling
ow.
Establishes the outdoor temperature at which to have the minimum ow
temperature of zone 2.
20 ÷ 40 35
R 15
Outdoor temper-
ature for Zone 2
low temperature
zone max cooling
ow.
Establishes the outdoor temperature at which to have the maximum ow
temperature of zone 2.
20 ÷ 40 25
R 16
Zone 2 low
temperature
zone minimum
cooling.
Denes the minimum ow temperature in zone 2 room cooling mode. 7 ÷ 20 18
R 17
Zone 2 low
temperature
zone maximum
cooling.
Denes the maximum ow temperature in zone 2 room cooling mode. 7 ÷ 25 20
Integration menu.
Id
Parameter
Parameter Description Range Default
Customised
value
I 01
DHW integration
enabling
Allows you to enable an alternative power source (AL) to integrate do-
mestic hot water heating.
OFF - AL AL
I 02
System integration
enabling
Using this function, you can enable an alternative (AL) power source to
integrate heating system central heating.
OFF - AL AL
I 03
DHW max wait
time.
Not used
I 04
Central heating max
wait time
Establishes the maximum amount of time before activating central heating
integration.
1 - 255
minutes
30
I 05
Integration activa-
tion mode
Establishes how to integrate the heat generator to the condensing unit,
you can choose between “AU” automatic and “MA” manual
AU - MA AU
I 06
Manual activation
temperature
Establishes the outdoor temperature under which central heating inte-
gration is enabled.
-15 ÷ 35 °C 2
I 07 Activation band
Establishes a temperature range around the calculated temperature to
determine which generator to switch on
0 ÷ 10 °C 5
I 08
Simultaneous
D.H.W.
Enables the simultaneous operation in DHW mode and room air con-
ditioning mode.
OFF - ON ON
I 11
Condensing unit
hours of operation
Displays the hours of operation performed by the Condensing unit - -
I 12
Indoor central
heating unit hours
of operation
Displays the hours of operation of the indoor central heating unit (op-
tional)
- -
I 13
Indoor D.H.W. unit
hours of operation
Displays the hours of operation of the indoor D.H.W. unit (optional) - -
Heat generator menu
Id
Parameter
Parameter Description Range Default
Customised
value
S 00
DHW minimum
no. of fan revs
Operating speed of the fan at minimum DHW output
900 ÷ 1500
(RPM)
G20: 1300
G30: 1300
G31: 1300
S 01
DHW maximum
no. of fan revs
Operating speed of the fan at maximum DHW output
3000 ÷ 6100
(RPM)
G20: 5100
G30: 4800
G31: 5400
S 02
Ignition phase fan
speed
Operating speed of the fan during the ignition phase 0 - 100% 15
