33
INSTALLERUSERMAINTENANCE TECHNICIAN
METHANE (G20) BUTANE (G30) PROPANE (G31)
THERMAL
POWER
THERMAL
POWER
CH
+
D.H.W.
BURNER GAS
FLOW RATE
PRESS. BURNER
NOZZLES
BURNER GAS
FLOW RATE
PRESS. BURNER
NOZZLES
BURNER GAS
FLOW RATE
PRESS. BURNER
NOZZLES
(kW) (kcal/h) (m
3
/h) (mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O)
32.0 27520 3.62 12.31 125.6 2.70 27.63 281.7 2.66 35.37 360.6
31.0 26660 3.51 11.68 119.1 2.62 26.05 265.6 2.58 33.48 341.4
30.0 25800 3.40 11.06 112.8 2.54 24.52 250.1 2.50 31.66 322.8
29.6 25423 3.36 10.80 110.1 2.51 23.87 243.4 2.46 30.88 314.9
28.0 24080 3.19 9.88 100.7 2.38 21.63 220.6 2.34 28.18 287.3
27.0 23220 3.08 9.31 94.9 2.30 20.26 206.6 2.26 26.51 270.4
26.0 22360 2.97 8.76 89.3 2.22 18.94 193.1 2.18 24.90 253.9
25.0 21500 2.87 8.22 83.8 2.14 17.67 180.2 2.10 23.33 237.9
24.0 20640 2.76 7.70 78.5 2.06 16.44 167.6 2.03 21.81 222.4
23.0 19780 2.65 7.19 73.3 1.98 15.26 155.6 1.95 20.34 207.4
22.0 18920 2.55 6.69 68.2 1.90 14.12 144.0 1.87 18.91 192.8
21.0 18060 2.44 6.21 63.3 1.82 13.02 132.8 1.79 17.52 178.7
20.0 17200 2.34 5.74 58.5 1.74 11.97 122.0 1.71 16.17 164.9
19.0 16340 2.23 5.28 53.8 1.66 10.96 111.7 1.64 14.87 151.6
18.0 15480 2.12 4.83 49.3 1.58 9.99 101.8 1.56 13.60 138.7
17.0 14620 2.01 4.40 44.9 1.50 9.06 92.3 1.48 12.38 126.2
16.0 13760 1.91 3.98 40.6 1.42 8.17 83.3 1.40 11.19 114.1
15.0 12900 1.80 3.57 36.4 1.34 7.32 74.6 1.32 10.04 102.4
14.0 12040 1.69 3.17 32.3 1.26 6.51 66.4 1.24 8.93 91.1
13.0 11180 1.58 2.78 28.3 1.18 5.74 58.5 1.16 7.86 80.1
12.9 11087 1.56 2.74 27.9 1.17 5.66 57.7 1.15 7.75 79.0
11.0 9460
D.H.W.
1.35 2.03 20.7 1.01 4.33 44.1 0.99 5.83 59.5
10.5 9030 1.30 1.86 18.9 0.97 4.00 40.8 0.95 5.35 54.5
Maior Eolo 32.
