IMO Go - Schematic Diagram of Router; Indicator Description; Interface Specification

1. Schematic Diagram of Router:
Indicator Descripon
ID appearance
Interface Specification
3
1
2
4
ITEM
INTRODUCTION
Indicator
2
1
Power buon
long press (3 seconds) to start on / off
the device
Sleep mode short press (less than 2
seconds) to exit Sleep
3
WPS buon
Long press (3 seconds) to open the WPS
mode
4
USB interface
Connect the USB cable to power adapter or
PC/Laptop
Baery indicator
Network Mode indicator
WiFi indicator
SMS indicator
