Genius Max Regulator (External Fittings)
Genius Max Regulator (GMX-53400-001 shown)
ITEM #
RK-GMAX
DESCRIPTION
Genius Max Sub Assy w/M12 x 1 fitting
Genius Max Sub Assy w/1/4" x 18 NPT
Fitting, LPG Inlet, Genius Max (M12 X 1)
Fitting, LPG Inlet, Genius Max (1/4"-18 Npt)
33 -
Filter, Inlet, Genius Max
34 -001, -002
O-Ring, Fluorocarbon (Fluorel/Viton) 0.07 Cs X .551 I.D.
35 -
Fitting, M8 X 1, Genius Max
36 -001, -002
O-Ring, Fluorocarbon (Fluorel/Viton) 0.070 Cs X .208 I.D.
37 -
Fitting, 12mm Hose BRC Standard
38 -
Fitting, Straight
39 -001, -002
O-Ring, Fluorocarbon (Fluorel/Viton) 0.070 Cs X .614 I.D.
40 -001, -002
Pin, Retainer (2)
32
31
-
-
