PARTS LIST
KEY NO. DESCRIPTION QUANTITY
1 Base Frame 1
2 Left Pedal Frame 1
3 Right Pedal Frame 1
4 Upper Frame 1
5 Lower Frame 1
6 Pulley Bracket 1
7 Handle Bar 1
8 Cable 1
9 Ø 5/8” Bushing 2
10 Hydraulic Shock 2
11 Pulley 1
12 Ø 2” End Cap 4
13 Left Pedal 1
14 Right Pedal 1
15 Knob Bolt 1
16 Ø 1 ¼” Bushing 4
17 Axle Cover 2
18 ST2.9 Philips Screw 2
19 Computer 1
20 Magnet Sensor Wire 1
21 Computer Sensor Wire 2
22 Magnet 1
23 M8 Regular Nut 2
24 Handle Grip 1
25 Rubber Bumper 2
26 Ø 7/8” End Cap 2
27 Ø ½” End Cap 1
28 M8 x 4” Allen Bolt 2
29 M8 x 1 ¾” Allen Bolt 4
30 M8 x 1 3/8” Allen Bolt 2
31 M8 x 1” Allen Bolt 2
32 M8 x 5/8” Allen Bolt 8
33 M10 x 1 ¾” Allen Bolt 1
34 M6 x 1 3/8” Philips Screw 4
35 M6 x 5/8” Philips Screw 2
36 Ø 5/8” Curved Washer 12
37 Ø 5/8” Lock Washer 10
38 Ø ½” Washer 4
39 Ø 5/8” Washer 12
40 Ø ¾” Washer 2
41 M8 Nut Cap 2
42 M8 Aircraft Nut 6
43 M10 Aircraft Nut 1
#5 Allen Wrench (Tool) 1
#6 Allen Wrench (Tool) 1
