─ 26 ─
Parts List and Exploded View
Inverter Frame ASSY
ItemNo.
Grade No. Part No. Description QTY
1 5.1.3.1 AC29900700 Inverter Frame 1
2 5.1.3.2 DC29002200 Wheel 2
3 5.1.3.3 GB894.125FH12 Circlip for shaft 2
4 5.1.3.4 DQ8DHS2B Washer Washer Φ9*Φ28*2 2
5 5.1.3.5 GB70M8*15DHS4 Socket Head Cap Screw M8*15 2
