Impulse AC2990 - Page 27

─ 27 ─
Parts List and Exploded View
Emergency Switch ASSY
ItemNo.
Grade No. Part No. Description QTY
1 1.4.1 AC29907700 Bottom Casing for Emergency Switch Pull Rope 1
2 1.4.2 AC29907500 Upper Casing for Emergency Switch 1
3 1.4.3 STDP4012 Safe Key Clamp 1
4 1.4.4 AC29907600
Upper Casing for Emergency Switch Pull Rope
1
5 1.4.5 GB846ST2.2*6.5DS Phillip Screw ST2.2*6.5 4
6 1.4.6 RT7507800 Locating Rod 2
7 1.4.7 RT7504900 The pressure spring 1
8 1.4.8 F89-M43025 Emergency Switch /W Wire 1
9 1.4.9 AC29907400 Bottom Casing for Emergency Switch 1
10 1.4.10 GB846ST2.9*13DS Phillip Screw ST2.9*13 4
