Impulse ES3000 - Page 50

─ 50 ─
Vertical Frame II ASSY
Lat Pulldown / Vertical Row Exploded View and Parts List
ITEM NO.
Description QTY
1 Vertical Frame Ⅰ ASSY 1
2 2" Pulley 1
3 3.5" Pulley 2
4 Hex Head Bolt M10*50 2
5 Flat Washer Φ11*Φ20*2 4
6 Nylon Lock Nut M10 3
7 3.5" Pulley Cover 2
8 Socket Head Cap Screw M10*50 1
