ITEM NO.
Description QTY
ITEM NO.
Description QTY
1 Bottom Frame Ⅱ ASSY 1 50 Back Pad 2 1
2 Vertical Frame Ⅱ ASSY 1 82 Seat Pad 3 1
3 Connection Frame 1 83 Back Pad 3 1
4 R24 Fixed Plate 1 101 Gear Hook 3
5 Top Frame Ⅱ ASSY 1 102 Selector Pin W/Coil 3
6 Back Frame ASSY 1 103 Weight Rubber Bumper 6
7 Middle Frame Ⅱ ASSY 1 104 Washer Φ11*Φ38*2 2
8 Fixed Plate 130 1 105 Flat Washer Φ11*Φ20*2 47
9 Long Lat Bar 1 106 Button Head Cap Screw M10*30 2
10 Row Handle 1 107 Washer Φ5.5*Φ10*1 8
11 Tube Frame ASSY 1 108 Screw M5*12 4
12 Small Top Frame ASSY 2 109 Nylon Lock Nut M5 4
13 Chain 1 110 Nylon Spacer 2
14 Cup Holder 2 111 Washer Φ9*Φ16*1.6 6
15 Guide Rod Φ25*2.5*1863 2 112 Spring Washer Φ8 12
16 FOAM 6 113 Hex Head Bolt M8*20 6
17 Guide Rod Φ25*2.5*1695 4 114 Socket Set Screw M8*8 12
18 Seat Pad 1 1 115 Nylon Lock Nut M10 19
20 L Plate 3 116 Hex Head Bolt M10*75 10
21 Shaft 6 117 Hex Head Bolt M10*80 4
24 Double Pulley ASSY 1 118 Hex Head Bolt M10*65 2
25 Pulley Bracket ASSY 1 119 Hex Head Bolt M10*50 2
28 FOAM Frame ASSY 1 120 Hex Head Bolt M10*20 4
30 Iron Shroud 3 121 Hex Head Bolt M10*60 2
31 Top Shroud Plate 2 122 Hex Head Bolt M10*105 2
32 Pulley Bracket W/Shaft ASSY 1 123 Mount Sleeve 6
37 Cable 1 1 124 Flat Washer Φ9*Φ22*1.6 16
38 Cable 2 1 125 Button Head Cap Screw M8*25 2
39 Foot Tube ASSY 1 126 Button Head Cap Screw M8*15 14
40 R20 Fixed Plate 1 127 Plastic Washer Φ60*Φ25.7*3 4
49 Seat Pad 2 1
To Next Page
