Parts List and Exploded View
Console Frame Assembly
Item No.
Grade No.
Part No. Description QTY
1 1.1 RT7000100 Console Frame 1
2 1.2 GB17880.3M8*16.5DS17 Countersunk head hexagon riveted nuts M8 4
3 1.3 GB17880.3M5*13DS17 Countersunk head hexagon riveted nuts M5 15
4 1.4 RT7000800 Console Plate Frame 1
5 1.5 RT7001600V1 Middle Z Fixing Plate 1
6 1.6 RT90012ASSY Handle Assembly 1
7 1.7 DQ8DS2A Washer Φ9*Φ22*2 6
8 1.8 GB70M8*15DS20 Scoket Head Cap Screw M8*15 4
9 1.9 GB70M8*20DS20 Scoket Head Cap Screw M8*20 4
10 1.10 GB70M8*55DS20 Scoket Head Cap Screw M8*55 2
11 1.11 NM8DS2 Locknut M8 2
12 1.12 RT7001500V1 Console Linked Plate 1
13 1.13 GB818M5*15DHS20 Phillip Screw M5*15 40
14 1.14 RT7003700 Console Left Up Cover 1
15 1.15 RT7003800 Console Right Up Cover 1
16 1.16 AC32705800 Clip Nut 4
17 1.17 GB5781M6*15DS2 Hex Head Bolt M6*15 4
18 1.18 RT7003500V1 Left Handle 1
19 1.19 RT7003600V1 Right Handle 1
20 1.20 GB818M5*35*35DS2 Phillip Screw M5*35 4
21 1.21 RT7003900V1 Console Left Down Cover 1
22 1.22 RT7004000V1 Console Right Down Cover 1
23 1.23 GB845ST4.2*13DS Phillip Screw ST4.2*13 6
24 1.24 RT7004800 Left Signing Light Fixing Plate 1
25 1.25 RT7004900 Right Signing Light Fixing Plate 1
26 1.26 RT7005200 Console Signing Light Cover 2
27 1.27 RT90013ASSY Fan Assembly 1
28 1.28 RT7006800 Switch Fixing Plate 1
29 1.29 B108 Switch Pcb 1
30 1.30 GB845ST2.9*6.5DS Phillip Screw ST2.9*6.5 6
31 1.31 L900JD-SM-VHR-10 Console Wire Up 1
32 1.32 DQCH02-SBD Ferrite 2
33 1.33 DQSWXT01-S Pulse Plate 1
34 1.34 L350XHB_XHB-3 Linked Wire Fron Pulse Pcb to PCB 1
35 1.35 AC32709906 The Receiver Cover 1
36 1.36 DQXTJS02 Receptor 1
37 1.37 SMJ10*1*1000 Tape 1
38 1.38 DQCH01-SBD Ferrite 3
