Impulse SL7046 User Manual

6
Exploded View and Parts List
Overall
Item No. Grade No. Part No. Description QTY
1 1 SL704601ASSY Left Frame ASSY 1
2 2 SL704602ASSY Right Frame ASSY 1
3 3 SL70460300 Rear Crossmember 1
4 4 SL704604ASSY Main Frame ASSY 1
5 5 ABS701307ASSY Foam Tube ASSY 2
6 6 SL703910ASSY Weight Horn ASSY 2
7 7 SL703911ASSY Weight Plate Storage ASSY 2
8 8 SL704608ASSY Left Arm Frame ASSY 1
9 9 SL704609ASSY Right Arm Frame ASSY 1
10 10 SL70461000ASSY Left Handle Frame ASSY 1
11 11 SL70461100ASSY Right Handle Frame ASSY 1
12 12 SL70462300 Pivot Shaft Φ25.4 3
13 13 SL704613ASSY Swing Frame ASSY 1
14 14 SL70462400 Pivot Shaft Φ30 2
15 15 SL950221ASSY Foam Pad 4
16 16 SL70462500 Back Pad 1
17 17 SL70461700 Seat Pad 1
18 18 SL70011600 Weight Horn Rubber Donut 2
19 19 SL70011700 Aluminum End Cap Φ54*Φ12.5*10.6 6
20 20 IN-D21202000 Aluminum End Cap Φ38*Φ10.5*8 6
21 21 IT95062000 Cap ASSY 4
22 22 IE95029100 Plastic Ring Φ60*Φ26*12 4
23 23 IN-S10111200 Sleeve Φ17*10.5 1
24 24 E7DZB1000 Plug Φ31.5*18 2
25 25 GB70M12*125DHS20 Socket Head Cap Screw M12*125 2
26 26 GB70M12*105DHS20 Socket Head Cap Screw M12*105 8
27 27 GB70M10*75DHS20 Socket Head Cap Screw M10*75 2
28 28 GB70M10*35*35DHS20NL Socket Head Cap Screw M10*35 4
29 29 GB70M10*30DHS20 Socket Head Cap Screw M10*30 2
30 30 GB70M8*25DHS20 Socket Head Cap Screw M8*25 1
31 31 CNLM12*50*50DS20NL Flat Head Cap Screw M12*50 2
32 32 CNLM12*30DS20NL Flat Head Cap Screw M12*30 4
33 33 CNLM10*30*30DS20NL Flat Head Cap Screw M10*30 6
34 34 GB77M8*10DS18NL Socket Set Screw M8*10 2
35 35 GB77M8*6DS18NL Socket Set Screw M8*6 4
36 36 GB9512DHS2 Flat Washer Φ13*Φ24*2.5 20
37 37 GB9510DHS2 Flat Washer Φ11*Φ23*2 4
38 38 GB958DHS2 Flat Washer Φ9*Φ16*1.6 1
39 39 NM12DHS2 Nylon Lock Nut M12 10
40 40 NM8DHS2 Nylon Lock Nut M8 1
41 41 NBS4DHS Hex Key S=4 1
42 42 NBS6DHS Hex Key S=6 1
43 43 NBS8DHS Hex Key S=8 1
44 44 NBS10DHS Hex Key S=10 1
